October 10, 2022 NHTSA CAMPAIGN NUMBER: 22V757000
Hydrostatic pump failure can cause a loss of power, limiting vehicle speed, and increasing the risk of a crash.
NHTSA Campaign Number: 22V757
Manufacturer Fontaine Modification
Components EQUIPMENT
Potential Number of Units Affected 56
Summary
Fontaine Modification (Fontaine) is recalling certain Fontaine-modified 2020-2023 Elgin Crosswind 1 and Elgin Whirlwind 1 sweepers built on Peterbilt 220 chassis. The engine air compressor stainless steel braided supply line may rub through the oil suction tube running from the Variable Power Divider (VPD) sump to the hydrostatic pump, causing the pump to fail.
Remedy
Fontaine will provide remedy instructions to Elgin Sweeper Company dealers to reroute the air line and inspect and repair any damage, free of charge. Owner notification letters were mailed October 24, 2022. Owners may contact Fontaine’s customer service at 1-800-366-8246.
Notes
Owners may also contact the National Highway Traffic Safety Administration Vehicle Safety Hotline at 1-888-327-4236 (TTY 1-800-424-9153), or go to www.nhtsa.gov.
SAFETY RECALL NOTICE
October 2022
Dear Elgin Sweeper Dealer:
This notice is sent to you in accordance with the requirements of the National Traffic and Motor Vehicle Safety Act.
Fontaine Modification® has decided that a defect which relates to the installation of the Variable Power Divider (VPD) exists in certain Elgin® Crosswind 1® and Elgin Whirlwind 1® sweepers manufactured from December 2018 through June 2022 with Peterbilt chassis. The chassis engine air compressor stainless steel braided supply line may rub through the oil suction tube running from the VPD sump to the hydrostatic pump. If the suction tube fails, cavitation to the hydrostatic pump will occur and cause severe damage to the hydrostatic system. This could cause the vehicle to move at limited speed. All Elgin® Crosswind 1® and Elgin® Whirlwind 1® sweepers built between June 2019 and May 2022 with Peterbilt
chassis will need to be repaired to resolve this issue.
WHAT WE WILL DO
Fontaine Modification® will cover the cost to relocate the engine air compressor stainless steel braided supply line away from the VPD oil suction tube. The standard repair time is 2.0 hours for a standard unit with no auxiliary water tanks or platforms mounted behind the cab. Fontaine will allow an additional 1.5 hours to remove and replace water tanks.
Please note: Because this issue can result in severe system failure and render the truck out of service for an extended period of time, this recall needs to be performed immediately.
Fontaine strongly recommends that all units are inspected/repaired before 1/31/2023 due to the potential damage to the VPD. This will help with your customer’s unit not being out of service an extended amount of time.
WHAT YOU SHOULD DO
If you are contacted by a customer for this recall, please contact Fontaine Modification® at 800.989.2113 or tim.wheeler@fontainemod.com with the last eight of the VIN of the chassis, to receive an warranty authorization number. Inspect the engine air compressor stainless steel braided supply line, to verify if it is touching the VPD oil suction tube. Please document the before and after of the relocation of the air line with pictures to send with invoice to Fontaine. See the attached work instructions for relocating the engine air compressor stainless steel braided supply line. Please inspect the VPD oil suction tube for any damage before removal.
FNT-103014025
Peterbilt 220 Air Line Relocation
Purpose:
This document proposes the evaluation criteria and subsequent repair requirements related to possible interference between the VPD suction oil line and the chassis air compressor discharge line on Peterbilt 220 chassis used on Elgin Crosswind1 and Whirlwind1 sweepers. Inspection of the units will determine which condition(s) exist and what repairs are required.
Chronology :
Fontaine received notification from Marmon Herrington of a unit that had a defective pump and motor. Fontaine installed the Variable Power Divider (VPD) on this unit. During the investigation of the root cause of the failure, it was found that the OEM stainless steel braided air compressor supply line was laying on top of the VPD hydraulic oil suction tube. This unit was in service for over 3 years with the stainless steel braided air compressor supply line in contact with the VPD hydraulic oil suction tube and wore a small hole in the suction tube. This caused air to enter the sealed hydraulic system causing damage to the pump and motor of the VPD.
4 Affected Products
Vehicle
MAKE | MODEL | YEAR |
ELGIN SWEEPER | CROSSWIND 1 (PB 220) | 2020-2023 |
8 Associated Documents
Recall Acknowledgement
RCAK-22V757-9351.pdf 646.462KB
Remedy Instructions and TSB
RCRIT-22V757-4536.pdf 2740.288KB
Defect Notice 573 Report
RCLRPT-22V757-8170.PDF 216.4KB
Manufacturer Notices(to Dealers,etc)
ISSUED Owner Notification Letter(Part 577)
RCONL-22V757-9086.pdf 142.869KB
Recall Quarterly Report #1, 2022-4
RCLQRT-22V757-6900.PDF 211.107KB
Recall Quarterly Report #2, 2023-1
RCLQRT-22V757-9568.PDF 211.206KB
Recall Quarterly Report #3, 2023-2
RCLQRT-22V757-7471.PDF 211.296KB
