NHTSA Campaign Number: 17V789
Manufacturer Grand Design RV
, LLC
Components EQUIPMENT
Potential Number of Units Affected 3,969
Power Tongue Jack may Operate Unintentionally
If the tongue jack retracts or extends unexpectedly, there could be an increased risk of a crash or injury.
Summary
Grand Design RV, LLC (Grand Design) is recalling certain 2017-2018 Reflection and Imagine travel trailers equipped with a Smart-Jack model power tongue jack. The laminated plastic touch pad on the jack may crack or separate allowing water to enter, potentially causing the jack to operate unintentionally.
Remedy
Grand Design will notify owners, and dealers will replace the power tongue jack, free of charge. The recall began on December 29, 2017. Owners may contact Grand Design customer service at 1-574-825-9679. Grand Design’s number for this recall is 900012.
Notes
Owners may also contact the National Highway Traffic Safety Administration Vehicle Safety Hotline at 1-888-327-4236 (TTY 1-800-424-9153), or go to www.safercar.gov.
GRAND DESIGN
RECREATIONALVEHICLES
Recall 17V-789
Claim Preparation & Repair Instructions
Please complete a warranty claim pre-authorization request using the following codes & labor times:
| LABOR: | Operation Code: | 910012 |
| Fault Code: | Recall | |
| Labor Time: | .5 hrs. | |
| Administrative Allowance: | .1 hrs. per unit | |
| PARTS: | #160166 — Power Tongue Jack | |
| PRE-AUTH REQUIREMENT: | Photo of Model & Serial Number Tag located at top of lift tube. | |
| REPAIR INSTRUCTIONS: | R&R Power Tongue Jack Assembly |
Promptly submit all pre-authorizations/claims through our Dealer Portal. If you have any questions or need assistance please call our Technical Service Team at 574-825-9249.
GRAND DESIGN
RECREATIONALVEHICLES
SAFETY RECALL # 17V-789
December 29, 2017
To: All Grand Design RV Dealers
Grand Design RV and Lippert Components, Inc. has decided that a safety defect exists in certain 2017-2018 Reflection and Imagine travel trailer vehicles. Accordingly, a recall to address this issue is being initiated effective December 29, 2017.
The defect involves Reflection & Imagine Travel Trailers manufactured between January 31, 2017 and August 25, 2017. VIN range of affected units is; Reflection-573TR3627H3312557 through 573TR3427J3315600 (non-sequential); Imagine-573TE272XH6600754 through 573TE3320J6603924 & 573TE2726J5500002 through 573TE2728J5500146 (sequential).
On affected vehicles, the power tongue jack may extend or retract on its own if the laminated plastic touch-pad is cracked or separated and water intrusion to the electronic control board were to occur. If jack extension were to occur while the trailer is under tow, the potential exists for a loss of vehicle control and/or crash. Repair involves replacing the power tongue jack with an updated version that incorporates circuit protection against water intrusion. The updated power tongue jacks are in stock and available for immediate shipment.
Owners of affected vehicles will be notified of this recall by mail from Grand Design RV. A copy of the Owner Notification Letter is attached for your reference. Also attached is a list of your retail sold and stock units affected by this recall. Finally, please find attached the repair and claim filing instructions associated with this recall action.
Please be reminded that it is a violation of Federal Law for you to sell or lease the products covered by this notification until repair under this recall has been performed. Substantial civil penalties apply to violations of this law. Your assistance with this recall is appreciated. Should you have any questions or concerns, please contact Grand Design Customer Service at 574-825-9679.
Respectfully,
GRAND DESIGN RV, LLC
11333 County Road 2, Middlebury, IN 46540 Phone: 574-825-8000, Fax: 574-825-9700 granddesignrv.com
Loading...
Reload document
Open in new tab
December 29, 2017
Loading...
December 21, 2017
Loading...
| “This site contains affiliate links for which OEMDTC may be compensated” |
SaleBestseller No. 1
POLESTAR Electric Trailer Jack, 5000lbs Electric Power A-Frame Tongue Jack with Waterproof Protective Cover & LED Light for Travel Trailer Camper, RV, 12V DC with Hard Wiring, 9"-27" Lift
- Heavy Duty Electric Trailer Jack - The POLESTAR 5000 lbs Electric Trailer Jack is built for powerful lifting power, designed to effortlessly handle trailers, RVs, boats, and off-road vehicles up to 5000 lbs. Whether you're stabilizing a heavy-duty trailer or performing demanding tasks, this jack provides exceptional strength and reliability, making it perfect for a wide range of hauling needs.
- Advanced Ball Screw Design for Superior Efficiency - At the heart of the POLESTAR electric trailer jack is its advanced ball screw design, which ensures smooth, efficient lifting and lowering. This high-precision mechanism reduces friction and wear, offering quicker, smoother, and more precise operation compared to traditional jacks. The ball screw design enhances the jack's lifting speed and overall performance, making trailer stabilization easier and more efficient than ever.
- Durable and Reliable - Crafted from durable, weather-resistant materials, the POLESTAR jack is built to endure the toughest outdoor environments. Its robust design ensures long-lasting performance, withstanding rain, snow, and sun exposure, so it remains a reliable companion for all your outdoor and heavy-duty tasks, it has a built-in circuit breaker that automatically trips and resets if the amperage is too high.
- Convenient and Efficient - The ball screw design works seamlessly with a powerful brake motor to provide consistent and stable lifting power. This combination ensures smoother operation, reduces strain, and offers enhanced control, allowing you to effortlessly raise and lower your trailer with minimal effort and maximum stability. Whether you're on an uneven camping site, parking lot, or incline, this electric jack ensures smooth, stable lifting for secure vehicle positioning.
- Versatile Lift Range - With a lift range from 9 inches (retracted) to 27 inches, Plus 4.5 inch Drop Leg, Up to 31.5 inches, the POLESTAR 5000 lbs electric trailer jack is versatile enough to handle a wide variety of trailer types and hauling tasks. Improved LEDs shine down onto your ball and coupler where light is needed the most.
SaleBestseller No. 2
Lippert Power Tongue Jack Electric Trailer A-Frame, 3,500 lbs. 18-Inch Stroke, 5.4-Inch Foot Pad, Durable Textured Casing, Emergency Manual Crank Override, 10.75" Retracted, 28.75" Extended - 285318
- EASY INSTALLATION — Complete with all necessary hardware and pins, installation for the Power Tongue Jack is fast and simple, so you can get to lowering and raising your equipment in no time
- TIME-SAVING — Say goodbye to cranking your manual jack. With the push of a button, you can raise or lower your a-frame trailer in a fraction of the time, without breaking a sweat
- INTEGRATED LIGHTING — Four integrated LED lights illuminate the ball and coupler, so you can operate your jack at night, worry-free
- POWERFULLY ENGINEERED — Built to do heavy lifting, the Power Tongue Jack has a 3,500 lb. lift capacity, helical-cut gears, 30 AMPs of power, and a 12V motor — all designed to get the job done, quietly and efficiently, so you don't have to
- BUILT TOUGH — Made from heavy-gauge, steel construction, a durable, textured housing that prevents chips and cracks, and a black powder-coat finish — this jack was designed to operate, day after day
Bestseller No. 3
VEVOR Electric Trailer Jack, Power Tongue Jack Weight Capacity 4000 lbs, 9.84"-33.85" Electric Tongue Jack with Waterproof Cover for Lifting RV Trailer, Horse Trailer, Utility Trailer, Yacht Trailer
- 【Heavy-Duty Load Capacity】 The VEVOR electric trailer jack boasts an impressive lifting capacity of 4000lbs, making it a powerful tool for lifting tasks. Provide reliable support for your towing needs!
- 【Quality You Can Trust】 Constructed from durable carbon steel with a protective coating, our power tongue jack ensures long-lasting performance and a new-like appearance. It's designed to withstand splashes and tough outdoor conditions.
- 【Provide All You Need】 The electric tongue jack comes with a sunshade waterproof cover, protecting against water and UV rays to prevent product aging. The 90° rotating installation hole prevents interference with the tailgate, ensuring a hassle-free installation process. Enjoy peace of mind knowing your tailgate will remain level.
- 【Multi-level Adjustable Height】 Our electric trailer tongue jack offers multi-level adjustable height, allowing you to keep your trailer level on various road surfaces. It fits for no matter high-profile or low-profile trailers. Say goodbye to trailer tilting.
- 【Versatile Application】 This power trailer jack is perfect for a wide range of applications. Whether you're lifting RV trailers, horse trailers, or utility trailers, it provides the strength and stability you need for effortless towing. In case of a power outage, the electric jack for trailers is equipped with a hand crank for emergency use.
SaleBestseller No. 4
Kohree Electric Trailer Jack 3700lbs, Heavy Duty RV Electric Power Tongue Jack Max 4000lbs for Travel Trailer A-Frame Camper, with Manual Crank Handle & Weatherproof Cover, 22" Lift, 12V DC Black
