NHTSA ID Number: 10095632
Manufacturer Communication Number: PMB-045
Summary
SERVICE MANUAL BULLETIN – MAN AXLE – LATERAL ROD INSTALLATION & ASSEMBLY.
1 Affected Product
Vehicle
PMB-045
ISSUE DATE: Jul 02 2015
Lateral Rod Installation & Assembly
MAN V8-65L
1 – FRONT AXLE & SUSPENSION
This bulletin provides a revised OEM breakdown for the Lateral Rod and the Lateral Rod Repair Kit used on your New Flyer
vehicle with MAN V8-65L axles.
This information supercedes all prior information on this subject already provided in your New Flyer Manuals. Make this Parts Bulletin available to service personnel to inform them of changed information.
SEOCONTENT-START
PARTS MANUAL BULLETIN
This Parts Manual Bulletin is prepared by the Publications Department of New Flyer Industries Canada
ULC. Refer to details below.
PMB-045 1 of 5 The New Flyer vehicles described in this manual may be protected by one or more
patents and design applications or registrations in the United States and Canada,
and in other countries. Refer to โVehicle Patent Informationโ in this manual.
Copyright ยฉ 2015 New Flyer Industries Canada ULC
PMB-045
ISSUE DATE: Jul 02 2015
APPLICABILITY
VEHICLE LENGTH ๏ฏ 30ft. ๏ฏ 35ft. ๏ฏ 40ft. ๏ฏ 60ft. ๏ฎ ALL
VEHICLE TYPE ๏ฏ High Floor ๏ฎ Low Floor ๏ฏ Inveroยฎ ๏ฏ Xcelsiorยฎ ๏ฏ ALL
FUEL TYPE
๏ฏ Diesel ๏ฏ Electric ๏ฏ CNG ๏ฏ LNG
๏ฎ ALL
๏ฏ Diesel/Electric ๏ฏ Gas/Electric ๏ฏ Fuel Cell
SUBJECT Lateral Rod Installation & Assembly
MAN V8-65L
SECTION TITLE 1 – FRONT AXLE & SUSPENSION
DETAILS This bulletin provides a revised OEM breakdown for the Lateral Rod and the Lateral
Rod Repair Kit used on your New Flyer vehicle with MAN V8-65L axles.
This information supercedes all prior information on this subject already provided
in your New Flyer Manuals. Make this Parts Bulletin available to service
personnel to inform them of changed information.
DRAFT
PARTS MANUAL BULLETIN PMB-045
LATERAL ROD INSTALLATION
2030113C.WMF
2 of 5 PMB-045
The New Flyer vehicles described in this manual may be protected by one or more
patents and design applications or registrations in the United States and Canada,
and in other countries. Refer to โVehicle Patent Informationโ in this manual.
Copyright ยฉ 2015 New Flyer Industries Canada ULC
Lateral Rod
Installation
2030113c.w
f
2030113c.w
f
4
5
3
2
1
DRAFT
ITEM QTY PART NUMBER DESCRIPTION
PARTS MANUAL BULLETIN PMB-045
LATERAL ROD INSTALLATION
2030113C.WMF
PMB-045 3 of 5
The New Flyer vehicles described in this manual may be protected by one or more
patents and design applications or registrations in the United States and Canada,
and in other countries. Refer to โVehicle Patent Informationโ in this manual.
Copyright ยฉ 2015 New Flyer Industries Canada ULC
1 1 018151 Lateral Rod, Front
1 1 018151NFA Lateral Rod, Front
2 2 20W12000 Washer, Flat Hardened 3/4″
3 1 103312 Pin, Cotter
4 2 050867 Screw, Hex Head Cap 3/4″ – 10 UNC x 3 1/2″ Lg.
5 2 042439 Nut, Lock Prevailing Torque 3/4″ – 10 UNC
DRAFT
PARTS MANUAL BULLETIN PMB-045
LATERAL ROD ASSEMBLY
PI00001103F
4 of 5 PMB-045
The New Flyer vehicles described in this manual may be protected by one or more
patents and design applications or registrations in the United States and Canada,
and in other countries. Refer to โVehicle Patent Informationโ in this manual.
Copyright ยฉ 2015 New Flyer Industries Canada ULC
Lateral Rod
Assembly
PI0000110
P00001999
????
????
????
????
????
????
????
????
DRAFT
ITEM QTY PART NUMBER DESCRIPTION
PARTS MANUAL BULLETIN PMB-045
LATERAL ROD ASSEMBLY
P00001999E
PMB-045 5 of 5
The New Flyer vehicles described in this manual may be protected by one or more
patents and design applications or registrations in the United States and Canada,
and in other countries. Refer to โVehicle Patent Informationโ in this manual.
Copyright ยฉ 2015 New Flyer Industries Canada ULC
1 1 018151 Lateral Rod Assembly, Front (Incl. 2…8)
1 1 018151NFA Lateral Rod Assembly, Front
2 1 NSS Bushing
3 1 NSS Ring, Internal Snap
4 1 NSS Ring, Lock
5 1 NSS Ring, Internal Snap
6 1 NSS Bushing
7 1 6342525 Nut, Castle M26 x 1.5
8 1 103312 Pin, Cotter
KIT 1 6313766 Lateral Rod Repair Kit – Curbside (Incl. 4…6)
KIT 1 6313766NFA Lateral Rod Repair Kit – Curbside (Incl. 4…8)
KIT 1 6387366 Lateral Rod Repair Kit – Streetside (Incl. 2 & 3)
DRAFT
