2018-2021 Aluminum Trailer Company ARV Gamechanger, & ARV Pro Bumper Pull Trailers Safety Chains Could Break

“This site contains affiliate links for which OEMDTC may be compensated”

March 12, 2021 NHTSA CAMPAIGN NUMBER: 21V171000

Safety Chains Could Break

The safety chains could break if the trailer disconnects from the tow vehicle, increasing the risk of a crash.



NHTSA Campaign Number: 21V171

Manufacturer Aluminum Trailer Company (ATC)

Components TRAILER HITCHES, EQUIPMENT

Potential Number of Units Affected 233



Summary

Aluminum Trailer Company (ATC) is recalling certain 2018-2021 ARV Gamechanger, and ARV Pro Bumper Pull trailers equipped with tandem 6,000 lb axles. The safety chains installed are rated at 11,700 lbs, which is insufficient for the trailer.



Remedy

ATC will notify owners and dealers will replace the existing safety chains with a safety chain that meets the GVWR rating of the trailer, free of charge. Owner notification letters were mailed on May 7, 2021. Owners may contact ATC customer service at 1-877-441-2440 ext. 342.



Notes

Owners may also contact the National Highway Traffic Safety Administration Vehicle Safety Hotline at 1-888-327-4236 (TTY 1-800-424-9153), or go to www.safercar.gov.




REPLACEMENT OF SAFETY CHAINS



PARTS PROVIDED:

  • 2 pcs – 1/2″-20 x 10″ Zinc Finish Grade 9 Hex Cap Screw (0019102)
  • 2 pcs – 1/2″-20 Zinc Finish Grade 9 Locknut (0019103)
  • 4 pcs – 1/2″ Yellow Zinc Finish SAE Flat Washer, 1.062″ Diameter (98639)
  • 2 pcs – 16,200# 3/8″ x 36″ GRD 7 Chain (0018674)



INSTRUCTIONS:

1. Loosen & remove (2) locknuts securing safety chains

a. Requires 3/4” socket/wrench

b. Note stack-up of washers above chains (Image 1)

c. Save washers, discard locknuts and chains



2. Remove (2) loosened bolts

a. Save washers, discard bolts



3. Install provided GR 9 bolts

a. Requires (1) washer under each bolt head



4. Add stack-up of washers to space chain away from tongue member

a. Might require additional washer(s) (four provided) (Image 1)



5. Add provided safety chains

a. Orient chains so hook openings face rearward when stretched outward (Image 2)



6. Install provided GR 9 locknuts

a. Requires (1) washer between chain link and locknut (Image 1)



7. Tighten locknuts

a. Position secured chain links perpendicular to tongue members (Images 1 & 2)

b. Torque to 80 ft/lbs





8 Affected Products

Vehicles

MAKEMODELYEAR
ATC ARVGAMECHANGER2018-2021
ATC ARVPRO BUMPER PULL2018-2021
