January 28, 2022 NHTSA CAMPAIGN NUMBER: 22E005000
A sudden loss of drive power increases the risk of a crash.
NHTSA Campaign Number: 22E005
Manufacturer Samsung SDI Co., Ltd.
Components ELECTRICAL SYSTEM
Potential Number of Units Affected 1,163
Summary
Samsung SDI Co., Ltd. (Samsung SDI) is recalling certain High Voltage Battery
Packs, part numbers LX68-10C790-G-PIA3AB, LX68-10C790-G-PIA3AD, 05193168AG, 05193168AH, LX68-10C790-G-PIA3AC, 05193168AE, and 05193168AF. The high voltage battery may fail, resulting in a sudden loss of drive power.
Remedy
Samusung SDI will notify and work with the affected vehicle manufacturers to replace the HV battery pack, free of charge. The manufacturer has not yet provided a schedule for recall notification. Ford owners may contact Ford customer service at 1-866-436-7332.
Notes
Owners may also contact the National Highway Traffic Safety Administration Vehicle Safety Hotline at 1-888-327-4236 (TTY 1-800-424-9153), or go to www.nhtsa.gov.
SAMSUNG SDI 573 CHRONOLOGY
January 28, 2022
On or about August 25, 2021, Ford contacted Samsung SDI regarding a potential issue in connection with an overheated HV battery busbar in one vehicle, and sought Samsung SDIโs assistance in analyzing the potential issue. Samsung SDI opened an investigation to assess the situation and any potential safety issues. As part of its investigation, Ford sent the battery module from the one vehicle with the identified potential HV battery busbar to Samsung SDI Hungary for analysis, which Samsung SDI Hungary received on or about September 21, 2021.
As the investigation began, on or about August 25, 2021, as a cautionary measure given Fordโs issue identification, Samsung SDI modified welding width and area limits in order to detect non-conforming High Voltage Batteries to enhance the welding quality of the busbars upon agreement with Ford.
On or about October 1, 2021, Samsung SDI Hungary reported a preliminary initial analysis of the battery module from Ford, and tentatively identified that the HV busbar was not seated properly, causing the pad to be mounted out of position prior to busbar welding, reducing the contact area between the cell terminal and the busbar. The reduced contact area identified would be likely to cause higher resistance leading to an overheat condition. Samsung SDIโs investigation continued, and Samsung SDI continued discussions with Ford.
On or about October 13, 2021, as its investigation continued, Samsung SDI identified 47 battery cell modules to Ford with the potentially non-conforming HV busbar welding, all associated with the one Ford vehicle. On or about November 5, 2021, Ford advised Samsung SDI that Ford had decided to conduct a field action for the affected vehicle. Ford filed its 573 report with NHTSA on November 10, 2021 (NHTSA Recall No. 21V-869), which the agency acknowledged on November 18, 2021.
On or about October 20, 2021, Nex+ implemented an advanced vision inspection system to screen out any nonconforming busbar without the manual inspection with the naked eye. As a result, after on or about October 27, 2021, Samsung SDI battery cell modules began to contain busbars produced after the implementation of the vision inspection system.
Samsung SDIโs investigation continued in December 2021, during which time, on December 23, 2021, NHTSA Recall Management Division contacted Samsung SDI, requesting that Samsung SDI provide by January 6, 2022 information about the purchasers to whom Samsung SDI sold the battery pack identified in Fordโs 573 report in
NHTSA Recall No. 21V-869, and further advised that Samsung SDI may be required to submit a Part 573 report to NHTSA under 49 C.F.R. 573.3(f) if manufacturers other than Ford were supplied. Samsung SDI immediately responded to NHTSA, and requested an extension of time to January 28, 2021 given the timing of the request before the holidays and need to conduct appropriate diligence. NHTSA granted the extension on January 4, 2022.
In or about late December 2021 and through mid-January 2022, Samsung SDIโs investigation continued, and identified additional battery packs with potentially non-conforming HV busbar welding issues sold to Ford and a second manufacturer, Stellantis, and continued discussions with both Ford and Stellantis. Following all these steps and diligence, with great respect for safety, NHTSA and the process, on Tuesday, January 25, 2022, Samsung SDI decided to file a Part 573 report with NHTSA as required by 49 C.F.R. 573.3(f).
1 Affected Product
Equipment
| BRAND | PART NO. | PRODUCTION DATES |
| SAMSUNG SDI | HIGH VOLTAGE BATTERY PACK | |
4 Associated Documents
Recall Acknowledgement
RCAK-22E005-3914.pdf 645.753KB
Loading...
Reload document
Open in new tab
Defect Notice 573 Report
RCLRPT-22E005-5563.PDF 217.382KB
Loading...
Recall 573 Report – 3/16/2022
RCLRPT-22E005-3386.PDF 217.506KB
Loading...
Miscellaneous Document – Chronology
RMISC-22E005-0247.pdf 91.711KB
Loading...
Latest Recalls Documents
| โThis site contains affiliate links for which OEMDTC may be compensatedโ |
- SS nuts set precisely designed for use with the Hybrid
Battery Pack modules of the following vehicles: Fit for Toyota Prius GEN II (2004-2009), ะขoัota ะ rius GEN III (2010-2015), ะขoัota ะ rius V (2012-2017), Lexus CT200h (2011 - 2017) - This kit will enable cleaner and more efficient connection of hybrid battery pack modules for lasting repairs
- The nut meets DIN 6923 specifications and is made of solid DIN/ISO A2-70 stainless steel for wear resistance. The bottom of the nut is smooth, even if it is tightened tightly, the bottom fitting will not be damaged
- Bus Bars are made of red copper with nickel plating, nickel plating provides extra protection and luster to copper while maintaining its excellent electrical conductivity, conductivity > 100 IACS.
- Package includes: 27* Nickel Plated Bus Bars (includes 1 extra busbar) 58* Stainless Steel Nuts (includes 2 extra nuts)
- COMPATIBILITY- Compatible with 2004-2015 Toyota Prius
- BENEFIT- Nickel Plating provides additional protection to copper against corrosion and tarnishing while retaining its excellent conductive properties,
- DESIGN- The serrated flange surface is designed for an excellent grip, which helps against backing out due to the vibration.
- MATERIAL- Due to its metallurgical properties, stainless steel flange nuts is an excellent choice to use in an abrasive environment
- EASY TO INSTALL - Manufactured according to factory specifications, 100% brand new. The installation process is simple and fast, and professional installation is strongly recommended.
- Direct replacement - this hybrid battery cooling fan matches the fit and function of the original fan on specific vehicle years, makes and models
- Restores operation - replacement keeps hybrid battery pack cool and functioning properly
- Thoroughly tested -vehicle try-on, air flow and life-cycle testing ensures product meets performance standards
- Trustworthy quality - backed by team of product experts and engineers in the United States
- Ensure fit - to make sure this part fits your exact vehicle, input your make, model and trim level into the garage tool
- Fits: for Toyota Prius GEN II 2004 2005 2006 2007 2008 2009, for Toyota Prius GEN III (2010 - 2015), for Toyota Prius V (2012-2017), for Lexus CT200h (2011 2012 2013 2014 2015 2016 2017)
- Product Material: Hybrid Battery Bus Bars: Copper Alloy, Nickel Plated. Serrated Flange nuts: Stainless Steel 304, Metric Hex
- Package Include: 28 (26+2 extra) Bus Bars and 60 (56 + 4 extra) Hex Flange Nuts
- Features: The original nut has a grain on the bottom, if you screw it too tight, the bottom parts will be damaged, but our improved nut has a smooth bottom, which avoids this problem
- Features: Nickel Plating provides additional protection to copper against corrosion and tarnishing, and together with a solid stainless steel serrated flange nuts, the kit will result in a clean and a more efficient connection of Hybrid Battery Pack modules for a long-lasting repair
- Perfect Match:Perfectly fit for for Toyota Prius 2004-2015. This Hybrid Battery Stainless Bus Bars & Nuts Set is an excellent choice for connection to Hybrid Battery modules.
- High-quality 304 Stainless Steel Materials:This Hybrid Battery Bus Bars & Flange Nuts are both made of high quality 304 stainless steel.Stainless steel Bus Bars & flange nuts are corrosion and wear resistant for long periods of grinding.
- Package Included:26PCS Bus Bars and 26PCS Flange Nuts are included.Direct replacement of the old original. No modification is need.
- Optimize Vehicle Performance:The threaded nuts provide good slip resistance and prevent retraction due to vibration.At the same time,the smooth stainless steel surface and oval shape of the Bus Bars prevent scratches on your car.
- Great Service Support:If you encounter any problems in the process of purchasing and using this product, please feel free to contact us. We will solve the problem for you in the first time and provide you with the best after-sales service.
- High quality rechargeable battery L70 Hybrid, L10, T2190, T2190G21, 14.4V/14.8V 6200mAh (size 37 x 37 x 130mm)
- Fast charging, smooth discharge, safe charging protection, durable interface, long use time, so that the machine as new work
- Long endurance, high quality cell and line protection, ensure the use of time
- Dual intelligent protection chip, active safety protection charging and discharging, short circuit protection, overcharge protection
- We provide 2 years after-sales service, if there is any problem, please feel free to contact us, we will reply in 24 hours
- Compatible with Toyota Prius 2010-06/2015.
- Note: Our nut has an improved bottom, smooth bottom, which will effectively prevent the bottom fitting from being damaged when overtightened
- Fit: for Toyota Prius GEN II 2004-2009, Prius GEN III 2010 - 2015, Prius V 2012-2017, CT200h 2011 - 2017
- Quantity: 27 (26 + 1 extra) C11000 Copper Alloy, Nickel Plated, Hybrid Battery Bus Bars & 58 (56 + 2 extra) ASTM-304 Stainless Steel, Metric Hex, Flange nuts
- Function: Nickel Plating provides additional protection to copper against corrosion and tarnishing, and together with a solid stainless steel serrated flange nuts, the kit will result in a clean and a more efficient connection of Hybrid Battery Pack modules for a long-lasting repair
- Fitment๏ผThis Hybrid Battery kit is Compatible with Gen 3 Toyota Prius (2010-2015)
- Enhanced performance๏ผPrecision-engineered copper wiring ensures optimal current flow for maximum hybrid battery performance and efficiency
- High quality materials๏ผThis Hybrid Battery Wire Harness are made of high quality materials to withstand the environment in the hybrid battery compartment for durability
- Easy installation๏ผColor-coded connectors and plug-and-play design make replacement straightforward with basic tools
- Note๏ผOnly the wiring harness is included, no other accessories
Last update on 2025-04-17 / Affiliate links / Images from Amazon Product Advertising API
This product presentation was made with AAWP plugin.
SEOCONTENT-START
OMB Control No.: 2127-0004
Part 573 Safety Recall Report 22E-005
The information contained in this report was submitted pursuant to 49 CFR ยง573
Manufacturer Name : Samsung SDI Co., Ltd.
Submission Date : JAN 28, 2022
NHTSA Recall No. : 22E-005
Manufacturer Recall No. : NR
Manufacturer Information :
Manufacturer Name : Samsung SDI Co., Ltd.
Address : 467, Beonyeong-ro
Seobuk-gu Cheonan-si 00 31086
Company phone : 419652400
Population :
Number of potentially involved : 1,163
Estimated percentage with defect : 14 %
Equipment Information :
Brand / Trade 1 : Samsung SDI
Model : High Voltage Battery Pack
Part No. : LX68-10C790-G-PIA3AB
Size : NR
Function : Propulsion
Descriptive Information : This recall campaign refers to NHTSA Part 573 filing 21V-869 reported by the
Ford Motor Company using the subject components. Recall campaign population
has been defined based on welding issues identified in Samsung SDIโs
manufacturing process and production data. Samsung SDI has identified battery
packs with potentially non-conforming HV busbar welding issues sold to Ford
and a second manufacturer, Stellantis. 1163 total units that may be affected
(Ford 1139, Stellantis 24).
Production Dates : JAN 03, 2020 – OCT 26, 2021
Brand / Trade 2 : Samsung SDI
Model : High Voltage Battery Pack
Part No. : LX68-10C790-G-PIA3AD
Size : NR
Function : Propulsion
Descriptive Information : This recall campaign refers to NHTSA Part 573 filing 21V-869 reported by the
Ford Motor Company using the subject components. Recall campaign population
has been defined based on welding issues identified in Samsung SDIโs
manufacturing process and production data. Samsung SDI has identified battery
packs with potentially non-conforming HV busbar welding issues sold to Ford
and a second manufacturer, Stellantis. 1163 total units that may be affected
(Ford 1139, Stellantis 24).
Production Dates : JAN 03, 2020 – OCT 26, 2021
Part 573 Safety Recall Report 22E-005 Page 2
The information contained in this report was submitted pursuant to 49 CFR ยง573
Brand / Trade 3 : Samsung SDI
Model : High Voltage Battery Pack
Part No. : 05193168AG
Size : NR
Function : Propulsion
Descriptive Information : This recall campaign refers to NHTSA Part 573 filing 21V-869 reported by the
Ford Motor Company using the subject components. Recall campaign population
has been defined based on welding issues identified in Samsung SDIโs
manufacturing process and production data. Samsung SDI has identified battery
packs with potentially non-conforming HV busbar welding issues sold to Ford
and a second manufacturer, Stellantis. 1163 total units that may be affected
(Ford 1139, Stellantis 24).
Production Dates : OCT 12, 2020 – JAN 26, 2021
Brand / Trade 4 : Samsung SDI
Model : High Voltage Battery Pack
Part No. : 05193168AH
Size : NR
Function : Propulsion
Descriptive Information : This recall campaign refers to NHTSA Part 573 filing 21V-869 reported by the
Ford Motor Company using the subject components. Recall campaign population
has been defined based on welding issues identified in Samsung SDIโs
manufacturing process and production data. Samsung SDI has identified battery
packs with potentially non-conforming HV busbar welding issues sold to Ford
and a second manufacturer, Stellantis. 1163 total units that may be affected
(Ford 1139, Stellantis 24).
Production Dates : OCT 12, 2020 – JAN 26, 2021
Brand / Trade 5 : Samsung SDI
Model : High Voltage Battery Pack
Part No. : LX68-10C790-G-PIA3AC
Size : NR
Function : Propulsion
Descriptive Information : This recall campaign refers to NHTSA Part 573 filing 21V-869 reported by the
Ford Motor Company using the subject components. Recall campaign population
has been defined based on welding issues identified in Samsung SDIโs
manufacturing process and production data. Samsung SDI has identified battery
packs with potentially non-conforming HV busbar welding issues sold to Ford
and a second manufacturer, Stellantis. 1163 total units that may be affected
(Ford 1139, Stellantis 24).
Production Dates : JAN 03, 2020 – OCT 26, 2021
Part 573 Safety Recall Report 22E-005 Page 3
The information contained in this report was submitted pursuant to 49 CFR ยง573
Brand / Trade 6 : Samsung SDI
Model : High Voltage Battery Pack
Part No. : 05193168AE
Size : NR
Function : Propulsion
Descriptive Information : This recall campaign refers to NHTSA Part 573 filing 21V-869 reported by the
Ford Motor Company using the subject components. Recall campaign population
has been defined based on welding issues identified in Samsung SDIโs
manufacturing process and production data. Samsung SDI has identified battery
packs with potentially non-conforming HV busbar welding issues sold to Ford
and a second manufacturer, Stellantis. 1163 total units that may be affected
(Ford 1139, Stellantis 24).
Production Dates : OCT 12, 2020 – OCT 26, 2021
Brand / Trade 7 : Samsung SDI
Model : High Voltage Battery Pack
Part No. : 05193168AF
Size : NR
Function : Propulsion
Descriptive Information : This recall campaign refers to NHTSA Part 573 filing 21V-869 reported by the
Ford Motor Company using the subject components. Recall campaign population
has been defined based on welding issues identified in Samsung SDIโs
manufacturing process and production data. Samsung SDI has identified battery
packs with potentially non-conforming HV busbar welding issues sold to Ford
and a second manufacturer, Stellantis. 1163 total units that may be affected
(Ford 1139, Stellantis 24).
Production Dates : OCT 12, 2020 – OCT 26, 2021
Description of Defect :
Description of the Defect : Welding issues identified in Samsung SDIโs manufacturing process (for certain
time periods identified in this report) during production of the high voltage
(HV) battery cell module (internal to the HV battery pack) may produce a high
resistance condition that commands the vehicle powertrain to stop.
FMVSS 1 : NR
FMVSS 2 : NR
Description of the Safety Risk : In the event of such high resistance, the HV battery pack may become
inoperative, and the vehicleโs propulsion system may be affected, increasing
the risk of loss of motive power.
Description of the Cause : Welding issues identified in Samsung SDIโs manufacturing process (for certain
time periods identified in this report) during production of the HV battery cell
Part 573 Safety Recall Report 22E-005 Page 4
The information contained in this report was submitted pursuant to 49 CFR ยง573
module may produce a high resistance condition that commands the vehicle
powertrain to stop. The HV busbar pad was not seated properly and/or the
power of the welding between the cell terminal and busbar was insufficient, in
either case, causing the weak welding between the cell terminal and the
busbar.
The weak welding causes higher resistance potentially leading to the defect
condition.
Identification of Any Warning
that can Occur :
NR
Involved Components :
Component Name : Holder bus bar
Component Description : Holder to assemble HV Busbar
Component Part Number : P073-00002A
Supplier Identification :
Component Manufacturer
Name : Nex+
Address : 39, Bueongsan-gil Seonjang-myeon
Asan-si, Chungcheongnam-do Foreign States
Country : Korea, Republic of
Chronology :
NR
Description of Remedy :
Description of Remedy Program : Samsung SDI will cooperate with affected vehicle manufacturers, including
Ford and Stellantis, to notify owners and instruct them to take their
vehicle to the appropriate dealer and replace the entire HV battery pack at
no cost to the owner. Reimbursement will be consistent with the vehicle
manufacturersโ respective reimbursement policies.
Part 573 Safety Recall Report 22E-005 Page 5
The information contained in this report was submitted pursuant to 49 CFR ยง573
How Remedy Component Differs
from Recalled Component :
The remedy battery cell module contains properly seated and welded
busbars.
Identify How/When Recall Condition
was Corrected in Production :
Samsung SDIโs good faith information and belief is that it has reasonably
identified the conditions arising in connection with the battery packs
identified above.
Recall Schedule :
Description of Recall Schedule : To be determined. Upon approval, owner notification letters will be
mailed no later than 60 days after submission of this report.
Planned Dealer Notification Date : NR – NR
Planned Owner Notification Date : NR – NR
Purchaser Information :
The following manufacturers purchased this defective/noncompliant equipment for possible use or
installation in new motor vehicles or new items of motor vehicle equipment:
Name : Ford Motor Company
Address : 330 Town Center Drive Suite 500
Dearborn MI 48126-2738
Country : US
Company Phone : 8664367332
Name : Stellantis
Address : 800 Chrysler Drive
Auburn Hills MI 48326-2757
Country : US
Company Phone : 8008531403
* NR – Not Reported
**************************************************************************************************************
OMB Control No.: 2127-0004
Part 573 Safety Recall Report 22E-005
The information contained in this report was submitted pursuant to 49 CFR ยง573
Manufacturer Name : Samsung SDI Co., Ltd.
Submission Date : MAR 16, 2022
NHTSA Recall No. : 22E-005
Manufacturer Recall No. : NR
Manufacturer Information :
Manufacturer Name : Samsung SDI Co., Ltd.
Address : 467, Beonyeong-ro
Seobuk-gu Cheonan-si 00 31086
Company phone : 419652400
Population :
Number of potentially involved : 1,163
Estimated percentage with defect : 14 %
Equipment Information :
Brand / Trade 1 : Samsung SDI
Model : High Voltage Battery Pack
Part No. : LX68-10C790-G-PIA3AB
Size : NR
Function : Propulsion
Descriptive Information : This recall campaign refers to NHTSA Part 573 filing 21V-869 reported by the
Ford Motor Company using the subject components. Recall campaign population
has been defined based on welding issues identified in Samsung SDIโs
manufacturing process and production data. Samsung SDI has identified battery
packs with potentially non-conforming HV busbar welding issues sold to Ford
and a second manufacturer, Stellantis. 1163 total units that may be affected
(Ford 1139, Stellantis 24).
Production Dates : JAN 03, 2020 – OCT 26, 2021
Brand / Trade 2 : Samsung SDI
Model : High Voltage Battery Pack
Part No. : LX68-10C790-G-PIA3AC
Size : NR
Function : Propulsion
Descriptive Information : This recall campaign refers to NHTSA Part 573 filing 21V-869 reported by the
Ford Motor Company using the subject components. Recall campaign population
has been defined based on welding issues identified in Samsung SDIโs
manufacturing process and production data. Samsung SDI has identified battery
packs with potentially non-conforming HV busbar welding issues sold to Ford
and a second manufacturer, Stellantis. 1163 total units that may be affected
(Ford 1139, Stellantis 24).
Production Dates : JAN 03, 2020 – OCT 26, 2021
Part 573 Safety Recall Report 22E-005 Page 2
The information contained in this report was submitted pursuant to 49 CFR ยง573
Brand / Trade 3 : Samsung SDI
Model : High Voltage Battery Pack
Part No. : LX68-10C790-G-PIA3AD
Size : NR
Function : Propulsion
Descriptive Information : This recall campaign refers to NHTSA Part 573 filing 21V-869 reported by the
Ford Motor Company using the subject components. Recall campaign population
has been defined based on welding issues identified in Samsung SDIโs
manufacturing process and production data. Samsung SDI has identified battery
packs with potentially non-conforming HV busbar welding issues sold to Ford
and a second manufacturer, Stellantis. 1163 total units that may be affected
(Ford 1139, Stellantis 24).
Production Dates : JAN 03, 2020 – OCT 26, 2021
Brand / Trade 4 : Samsung SDI
Model : High Voltage Battery Pack
Part No. : 05193168AE
Size : NR
Function : Propulsion
Descriptive Information : This recall campaign refers to NHTSA Part 573 filing 21V-869 reported by the
Ford Motor Company using the subject components. Recall campaign population
has been defined based on welding issues identified in Samsung SDIโs
manufacturing process and production data. Samsung SDI has identified battery
packs with potentially non-conforming HV busbar welding issues sold to Ford
and a second manufacturer, Stellantis. 1163 total units that may be affected
(Ford 1139, Stellantis 24).
Production Dates : OCT 12, 2020 – OCT 26, 2021
Brand / Trade 5 : Samsung SDI
Model : High Voltage Battery Pack
Part No. : 05193168AF
Size : NR
Function : Propulsion
Descriptive Information : This recall campaign refers to NHTSA Part 573 filing 21V-869 reported by the
Ford Motor Company using the subject components. Recall campaign population
has been defined based on welding issues identified in Samsung SDIโs
manufacturing process and production data. Samsung SDI has identified battery
packs with potentially non-conforming HV busbar welding issues sold to Ford
and a second manufacturer, Stellantis. 1163 total units that may be affected
(Ford 1139, Stellantis 24).
Production Dates : OCT 12, 2020 – OCT 26, 2021
Part 573 Safety Recall Report 22E-005 Page 3
The information contained in this report was submitted pursuant to 49 CFR ยง573
Brand / Trade 6 : Samsung SDI
Model : High Voltage Battery Pack
Part No. : 05193168AG
Size : NR
Function : Propulsion
Descriptive Information : This recall campaign refers to NHTSA Part 573 filing 21V-869 reported by the
Ford Motor Company using the subject components. Recall campaign population
has been defined based on welding issues identified in Samsung SDIโs
manufacturing process and production data. Samsung SDI has identified battery
packs with potentially non-conforming HV busbar welding issues sold to Ford
and a second manufacturer, Stellantis. 1163 total units that may be affected
(Ford 1139, Stellantis 24).
Production Dates : OCT 12, 2020 – JAN 26, 2021
Brand / Trade 7 : Samsung SDI
Model : High Voltage Battery Pack
Part No. : 05193168AH
Size : NR
Function : Propulsion
Descriptive Information : This recall campaign refers to NHTSA Part 573 filing 21V-869 reported by the
Ford Motor Company using the subject components. Recall campaign population
has been defined based on welding issues identified in Samsung SDIโs
manufacturing process and production data. Samsung SDI has identified battery
packs with potentially non-conforming HV busbar welding issues sold to Ford
and a second manufacturer, Stellantis. 1163 total units that may be affected
(Ford 1139, Stellantis 24).
Production Dates : OCT 12, 2020 – JAN 26, 2021
Description of Defect :
Description of the Defect : Welding issues identified in Samsung SDIโs manufacturing process (for certain
time periods identified in this report) during production of the high voltage
(HV) battery cell module (internal to the HV battery pack) may produce a high
resistance condition that commands the vehicle powertrain to stop.
FMVSS 1 : NR
FMVSS 2 : NR
Description of the Safety Risk : In the event of such high resistance, the HV battery pack may become
inoperative, and the vehicleโs propulsion system may be affected, increasing
the risk of loss of motive power which may increase the risk of a crash.
Description of the Cause : Welding issues identified in Samsung SDIโs manufacturing process (for certain
time periods identified in this report) during production of the HV battery cell
Part 573 Safety Recall Report 22E-005 Page 4
The information contained in this report was submitted pursuant to 49 CFR ยง573
module may produce a high resistance condition that commands the vehicle
powertrain to stop. The HV busbar pad was not seated properly and/or the
power of the welding between the cell terminal and busbar was insufficient, in
either case, causing the weak welding between the cell terminal and the
busbar.
The weak welding causes higher resistance potentially leading to the defect
condition.
Identification of Any Warning
that can Occur :
NR
Involved Components :
Component Name : Holder bus bar
Component Description : Holder to assemble HV Busbar
Component Part Number : P073-00002A
Supplier Identification :
Component Manufacturer
Name : Nex+
Address : 39, Bueongsan-gil Seonjang-myeon
Asan-si, Chungcheongnam-do Foreign States
Country : Korea, Republic of
Chronology :
NR
Description of Remedy :
Description of Remedy Program : Samsung SDI will cooperate with affected vehicle manufacturers, including
Ford and Stellantis, to notify owners and instruct them to take their
vehicle to the appropriate dealer and replace the entire HV battery pack at
no cost to the owner. Reimbursement will be consistent with the vehicle
manufacturersโ respective reimbursement policies.
Part 573 Safety Recall Report 22E-005 Page 5
The information contained in this report was submitted pursuant to 49 CFR ยง573
How Remedy Component Differs
from Recalled Component :
The remedy battery cell module contains properly seated and welded
busbars.
Identify How/When Recall Condition
was Corrected in Production :
Samsung SDIโs good faith information and belief is that it has reasonably
identified the conditions arising in connection with the battery packs
identified above.
Recall Schedule :
Description of Recall Schedule : Not applicable (Samsung SDI does not have dealers and/or distributors,
and Samsung SDI understands that notice is being issued by Ford and
Stellantis). Samsung SDI understands that Ford and Stellantis will
provide recall completion rate information required by 49 CFR 573.7
because they will be conducting the recall campaign. See 49 CFR 573.3(f)
Planned Dealer Notification Date : NR – NR
Planned Owner Notification Date : NR – NR
Purchaser Information :
The following manufacturers purchased this defective/noncompliant equipment for possible use or
installation in new motor vehicles or new items of motor vehicle equipment:
Name : Ford Motor Company
Address : 330 Town Center Drive Suite 500
Dearborn MI 48126-2738
Country : US
Company Phone : 8664367332
Name : Stellantis
Address : 800 Chrysler Drive
Auburn Hills MI 48326-2757
Country : US
Company Phone : 8008531403
* NR – Not Reported
**************************************************************************************************************
SEOCONTENT-END
