NHTSA Campaign Number: 15V018
Manufacturer Frontline Communications
Components EQUIPMENT ADAPTIVE
Potential Number of Units Affected 9
Wheelchair Lift – Platform Cracking
If the platform side plates crack, the lift platform can separate from the lift and come to rest against the vehicle’s lift door. When the doors are opened, the platform may fall out, increasing the risk of injury to the lift operator.
Summary
Frontline Communications (Frontline) is recalling certain model year 2007-2011 Mobile Medical Unit vehicles manufactured from December 13, 2007, to February 17, 2011, and equipped with certain model S2005, S2010, S5005, S5010, S5505, and S5510 wheelchair lifts manufactured by Ricon Corporation. The platform side plate of the affected wheelchair lifts may crack.
Remedy
Frontline will notify owners to contact Ricon Customer Service to arrange for the installation of supplemental platform support bumpers. Any platform that has already started cracking will be replaced, free of charge. The recall began on February 25, 2015. Owners may contact Frontline customer service at 1-727-573-0400, or Ricon customer service at 1-800-322-2884.
Notes
Owners may also contact the National Highway Traffic Safety Administration Vehicle Safety Hotline at 1-888-327-4236 (TTY 1-800-424-9153), or go to www.safercar.gov.
SERVICE BULLETIN
| Subject: | S-Series Platforms: 34in. x 54in., 32in. x 51in. |
|---|---|
| Applicable Products: | S1205, S2005, S2010, S5005, S5010, S5505, S5010 |
| Effectivity: | 6/24/2014 |
RICON SERVICE BULLETINS ARE FOR USE BY PROFESSIONAL SERVICE TECHNICIANS, AND ARE NOT INTENDED FOR USE BY NON-PROFESSIONALS OR AMATEURS. SERVICE BULLETINS ALERT TECHNICIANS TO ISSUES THAT MAY OCCUR WITH RICON PRODUCTS, AND ARE INTENDED TO ASSIST THE TECHNICIAN IN THE PROPER SERVICE OF THOSE PRODUCTS.
PROFESSIONAL SERVICE TECHNICIANS HAVE THE BACKGROUND AND KNOWLEDGE TO PERFORM MAINTENANCE WORK PROPERLY AND SAFELY.
AN ISSUE DESCRIBED BY A SERVICE BULLETIN DOES NOT NECESSARILY APPLY TO EVERY UNIT IN A PRODUCT LINE. A RICON AUTHORIZED SERVICE TECHNICIAN WILL BE ABLE TO DETERMINE WHICH UNITS CAN BENEFIT FROM THE INFORMATION PROVIDED HERE.
Introduction
This bulletin provides a brief description of a technical issue related to the inspection and possible replacement of the platform assembly of certain S-Series wheelchair lifts.
Incorporation
Inspection and possible replacement of the platform assembly used on wheelchair lift configurations beginning with the following part numbers:
S1205, S2005, S2010, S5005, S5010, S5505, S5510
Information
Under certain conditions the side plate of the larger platforms included on the subject S-Series model wheelchair lifts can exhibit cracking while in the stowed position which, if left unchecked can propagate to the point where separation of the rear portion of the side plate occurs rendering the lift inoperable and possibly unsafe to use.
Cause
The cracking as illustrated has been observed on less than 5% of the subject population and appears to be caused by a combination of factors including but not necessarily limited to, incomplete stowing of the lift and/or maladjustment or otherwise malfunctioning of the stow lock devise combined with a violent side- to- side movement that might be associated with traversing curbs, speed bumps and other variable road conditions, especially at higher speeds.
Corrective Action
If cracks are found, the platform must be replaced as soon as possible. Use the following part numbers for the associated model numbers.
| For Models S1205-G, S1205VG | Use PN 33851 |
| For Models S2005-S, S5005-S, S2005-T, S5005-T | Use PN V2-PF-389 |
| For Models S2005-F, S5005-F, S2005-G, S2005-C, S2005VF, S2005-J | Use PN 32466 |
| For Models S2005-L, S5005-L | Use PN 38330 |
| For Models S2010-S, S2010-T, S5010-S, S5010-T | Use PN 16622 |
| For Models S2010VF, S2010-C, S2010-F, S5010-F | Use PN 32469 |
| For Models S5505-S | Use PN 34846 |
| For Models S5505VF, S5505-C, S5505-F | Use PN 33485 |
| For Models S5510VF, S5510-F, S5510C, S5510-J | Use PN 34249 |
