Navistar, Inc.
2701 Navistar Drive
Lisle, IL 60532 USA
navistar.com
A NAVISTAR COMPANY
IMPORTANT SAFETY RECALL 23507
INTERIM NOTICE
NHTSA RECALL NO. 23V-170
This notice applies to your vehicle identified on the
enclosed card.
MAY 2023
Mailed on
05/12/2023
Compliance
Dear INTERNATIONAL® Customer,
This notice is sent to you in accordance with the requirements of
the National Traffic and Motor Vehicle Safety Act.
Navistar has decided that a defect which relates to motor vehicle
safety exists in certain 2020 thru 2024 HX series trucks built
03/13/2019 thru 02/28/2023.
REASON FOR THIS RECALL
Over time, the grille surround may become loose from the eight
(8) mounting brackets that secure it to the hood. This may cause
the grille surround to separate from the truck.
RISK TO MOTOR VEHICLE SAFETY
A grille surround that separates from the truck and falls to the
roadway while the vehicle is in operation, can increase the risk of
a vehicle crash that may result in property damage, personal
injury, or death.
DEFECT REMEDY
A final remedy has been determined. Parts are on order but
availability is unknown at this time. When parts for the final
remedy become available, you will be notified of additional
actions you should take.
ACTIONS YOU SHOULD TAKE IN THE INTERIM
To minimize the potential occurrence of this defect in the
interim period, inspect the grille surround for looseness with
every pre and post trip inspections until the final remedy
becomes available.
If any looseness is detected and/or the grille surround DID
separate from 1 or more mounting brackets you should schedule
an appointment with any International® dealer to have the interim
repair performed to your vehicle. You can find your nearest
dealer by using the dealer locator at
https://www.internationaltrucks.com/dealer-locator or by calling 1-
800-448-7825.
If no looseness is detected and/or there is no separation of
the grille surround from any of the mounting brackets, ,
continue inspecting for looseness during your pre and post
trip inspections until you receive notice when the final
remedy becomes available.
The interim repair will involve adding external rivets to the grille
surround to ensure It stays attached to its mounting brackets and
will take approximately 1 hour and 15 minutes and up to 2 hours
and 15 minutes to complete.
If you have already paid for repairs prior to this notice that
corrected the defect, you may be eligible for reimbursement of
certain repair expenses if they occurred 03/16/2022 thru
05/25/2023. Present your original repair paperwork and proof
of payment to any INTERNATIONAL® dealer and your eligibility
will be reviewed. You may also submit a claim using the enclosed
Request for Reimbursement card.
If you are the lessor of this vehicle, please forward a copy of
this notice to the lessee within ten days to comply with federal
regulations.
If you do not own this vehicle, please fill out and return mail
the enclosed card so that you will not be contacted again about
this recall.
IF YOU NEED FURTHER ASSISTANCE
If you believe that Navistar has failed to remedy the defect
without charge or within a reasonable time, please follow the
procedure described in the Owner Assistance Guide section in
your Owner’s Manual or call toll free 1-800-448-7825.
You may also submit a complaint to the Administrator, National
Highway Traffic Safety Administration, 1200 New Jersey Ave,
SE, Washington, DC 20590; or call the toll free Vehicle Safety
Hotline at 1-888-327-4236 (TTY: 1-800-424-9153); or go to
http://www.safercar.gov.
Navistar requests your prompt attention and patience regarding
the correction of this defect and apologizes for any
inconvenience this may cause you.
Navistar, Inc.

**************************************************************************************************************

INTERIM SERVICE
PROCEDURE
SUBJECT: SAFETY RECALL
23507
May, 2023
Grille surround on certain 2020 thru 2024
International® HX® Series trucks built 03/13/2019
thru 02/28/2023
CUSTOMER LETTER
Print ready (PDF file) copy of the Customer Letter
DEFECT DESCRIPTION
Over time, the grille surround may come loose from the eight mounting brackets
that secure it to the hood. This may cause the grille surround to separate from
the truck. A grille surround that separates from the truck and falls to the roadway
while the vehicle is in operation can increase the risk of a vehicle crash that may
result in property damage, personal injury, or death.
MODELS INVOLVED
This safety recall involves certain 2020 thru 2024 International® HX® Series
trucks built 03/13/2019 thru 02/28/2023.
ELIGIBILITY
This procedure applies ONLY to vehicles marked in the International® Service
Portal8M with Safety Recall 23507. Also complete any other open campaigns
listed on the Service Portal at this time.
VEHICLE RECALL 23507
© 2023 Navistar, Inc. All rights reserved. All marks are trademarks of their respective owners. 1
SPECIAL TOOLS
Tool Description Part Number
Rivet Gun Rivet Gun with mandrel for 3/16-inch N/A
diameter rivets (manual or pneumatic)
#11 Drill Bit Drill Bit N/A
Black Permanent Black Permanent Marker N/A
Marker
Pneumatic Grinder Pneumatic Grinder N/A
Pneumatic Rotary Pneumatic Rotary Sanding Wheel N/A
Sanding Wheel
PARTS INFORMATION
CAUTION! To prevent damage to property, the rivets specified for this
repair must be used and NOT substituted with any other type. These rivets
are available from the sources listed in the table below.
Part Number Part Description Quantity
Fastenal P/N: 126282 Rivet: 3/16-in Dia. Stainless Steel 28
Grainger P/N: 97525A490 w/0.125-in-0.25-in Grip Range
McMaster-Carr P/N: 3ZKT1
NPN / Source Locally Heavy Double-Sided Tape As
Needed
SERVICE PROCEDURE
WARNING! To prevent personal mJury and / or death, or damage to
property, park vehicle on hard flat surface, turn the engine off, set the
parking brake and install wheel chocks to prevent the vehicle from moving
in either direction.
WARNING! To prevent personal injury and/ or death, always wear safe eye
protection when performing vehicle maintenance.
WARNING! To prevent personal injury and / or death, or damage to
property, allow engine/ vehicle components to cool before servicing.
WARNING! To prevent personal injury and / or death, or damage to
property, keep flames or sparks away from vehicle and do not smoke while
servicing the vehicle’s batteries. Batteries expel explosive gases.
VEHICLE RECALL 23507
© 2023 Navistar, Inc. All rights reserved. All marks are trademarks of their respective owners. 2
1. Park vehicle on flat surface.
2. Shift transmission to Park or Neutral and set parking brake.
3. Turn vehicle ignition to Key OFF position.
4. Install wheel chocks.
NOTE: ONLY grille surrounds found loose shall receive the interim repair.
There should be no inspection only claims so the recall stays open should
the grille surround become loose prior to final Remedy.
NOTE: Refer to Figure 3 for HX615 and HX620 models. Refer to Figure 4 for
HX520 models to determine where the mounting brackets are located.
5. Using hand force, pull the grille surround away from the hood to see if one or
more brackets have de-bonded from the grille surround.
a. If one or more areas of the grille surround moves, proceed to Step 6.
b. If the grille surround does not move, then no repair is required at this time.
Proceed to Step 28.
VEHICLE RECALL 23507
© 2023 Navistar, Inc. All rights reserved. All marks are trademarks of their respective owners. 3
Instructions for Grille Surround Removal for HX615 and HX620 Series
Trucks
6. Unlatch and open hood.
———–·-·-
4
Figure 1. HX615 and HX620 Models Grille Surround Removal
1. MB palnut (2)
2. Grille assembly
3. MB Keps nut (8)
4. Grille surround
7. Remove eight MB Keps nuts (Figure 1, Item 3) from the back of grille
surround (Figure 1, Item 4 ). Save Keps nuts for reuse.
3
0000477929
8. Remove grille assembly (Figure 1, Item 2) from truck by pushing inward and
rotating 90 degrees to remove it through hood opening.
9. Remove two palnuts from stud (Figure 1, Item 1) by rotating them
counterclockwise. Save palnuts for reuse.
10. Remove grille surround (Figure 1, Item 4) from hood and place face down
on a clean, protected workbench.
VEHICLE RECALL 23507
© 2023 Navistar, Inc. All rights reserved. All marks are trademarks of their respective owners. 4
Instructions for Grille Surround Removal for HX520 Series Trucks
1 \
2
0000477930
Figure 2. HX520 Model Grille Removal
1. Grille surround
2. MB prevailing torque nut (8)
3. MB Tone® bolts (8)
4. Grille assembly
NOTE: The eight MS Tone® bolts must be returned to their original positions
when grille assembly is installed. (MS Tone® bolts vary in length.)
11. With hood closed, remove eight MB Tone® bolts (Figure 2, Item 3) from
center of grille assembly (Figure 2, Item 4). Save Tone® bolts for reuse.
12. Remove grille assembly (Figure 2, Item 4) and safely set aside.
13. Remove eight MB prevailing torque nuts (Figure 2, Item 2) from back of
grille surround (Figure 2, Item 1 ). Save nuts for reuse.
14. Remove grille surround from hood and place face down on a clean,
protected workbench.
NOTE: All support brackets must be repaired whether they are still
attached, loose on one pad and not fully detached, or fully detached.
15. Determine condition of support bracket mounting.
VEHICLE RECALL 23507
© 2023 Navistar, Inc. All rights reserved. All marks are trademarks of their respective owners. 5
16. For each support bracket that is loose on one pad but not fully detached,
perform the following:
a. Press the loose pad back down to the original location on the back side
of the grille surround.
b. Using heavy double-sided tape or a clamp, hold support bracket in place
on grille surround for drilling and riveting.
17. For each support bracket that is fully detached from the grille surround,
perform the following:
a. Using pneumatic grinder with rotary sanding wheel, clean rust and I or
corrosion from both the grille surround and the mounting surface of the
support brackets.
b. Apply a 2-inch strip of heavy double-sided tape to each pad of the
mounting brackets.
c. Install the detached mounting brackets into their correct location on the
hood.
i. For HX615 and HX620 Series trucks, install the M8 Keps nuts to
hold the mounting brackets in place for each separated mounting
bracket.
ii. For HX520 Series trucks, install eight M8 prevailing torque nuts to
hold the mounting brackets in place. Install M8 prevailing torque nut
to hold each separated mounting bracket to keep it in place.
d. Once all brackets are installed and secured, install grille surround onto
the hood.
e. Apply hand pressure at each location of grille surround. Use the palm of
one hand on the grille surround and the fingers of your other hand on
the back side of bracket.
f. Once pressure has been applied to each location, remove nuts installed
in step 17. c. i or Step 17. c. ii, and remove grille surround.
g. Proceed to Step 18.
VEHICLE RECALL 23507
© 2023 Navistar, Inc. All rights reserved. All marks are trademarks of their respective owners. 6
NOTE: Refer to Figure 3 for HX615 and HX620 drill locations.
Figure 3. HX615 and HX620 Drill Locations
1. Drill location (28)
VEHICLE RECALL 23507
© 2023 Navistar, Inc. All rights reserved. All marks are trademarks of their respective owners. 7
NOTE: Refer to Figure 4 for HX520 drill locations.
Figure 4. HX520 Drill Locations
1. Drill location (28)
18. Drill 28 #11 diameter holes from back side.
a. Refer to Figure 3 for HX615 and HX620 Series trucks.
b. Refer to Figure 4 for HX520 Series trucks.
0000477932
19. Once all holes have been drilled, turn grille surround over, deburr each hole
taking care not to increase the diameter, and install rivets from front side in
all 28 locations.
20. Once all rivets have been installed, inspect each rivet for correct installation.
VEHICLE RECALL 23507
© 2023 Navistar, Inc. All rights reserved. All marks are trademarks of their respective owners. 8
Instructions for Grille Surround Installation on HX615 and HX620 Series
Trucks
21. With hood in open position, install grille surround and position on hood and
install palnuts.
22. Install grille assembly inserting it through hood front opening, rotate grille 90
degrees, and position into place.
23. Install eight M8 Keps nuts.
24. Close and latch hood.
25. Remove wheel chocks.
Instructions for Grille Surround Installation on HX520 Series Trucks
26. With hood in closed position, install grille surround and position on hood and
install prevailing torque nuts.
27. Position grille into place and install M8 Tone® bolts.
28. Remove wheel chocks.
END OF SERVICE PROCEDURE
LABOR INFORMATION
Operation Number Description Time
A40-23507-1 R&R Grille Surround, Drill & Install Rivets 0.8 hrs
A40-23507-2 Reattach One or Two Brackets 0.9 hrs
A40-23507-3 Reattach Three or Four Brackets 1.0 hrs
A40-23507-4 Reattach Five Brackets 1.1 hrs
A40-23507-5 Reattach Six Brackets 1.2 hrs
VEHICLE RECALL 23507
© 2023 Navistar, Inc. All rights reserved. All marks are trademarks of their respective owners. 9
CAMPAIGN IDENTIFICATION LABEL
Each vehicle corrected in accordance with this
campaign must be marked with a CTS-1075
Campaign Identification Label.
Complete the label and attach on a clean surface next
to the vehicle identification number (VIN) plate.
ADMINISTRATIVE/ DEALER RESPONSIBILITIES
WARRANTY CLAIMS
COMPLETED
Service Location Code I
Warranty claim expense is to be charged to Warranty. Claims are to be
submitted in the normal manner, making reference to Safety Recall 23507.
Section 7 of the Warranty Policy and Procedures Manual contains further
information related to the submission and processing of AFC / Recall claims.
As with all claim submissions, items acquired locally must be submitted in the
“Other Charges” tab. The cost of any bulk items (such as a bag of cable tie
straps, roll of wire, barrel of oil, or tube of silicone) should be prorated for the cost
of the individual pieces/ amount used during each repair.
GROUP
GROUP – Enter n umber
NOUN – Leave b lank ~ –
+– I
–
C (CAUSE) – Ente r either 1, 2, 3. (See below)
1. Inspected (No repair required).
2. Inspected and repaired.
3. Defective part from parts stock.
–
arranty Code) Enter 40.
I
WARRANTY – (W
TYPE PART – En
PAD-Enter -00
ter P for type part causing failure.
~
VEHICLE RECALL 23507
I
—
NOUN C WARR. TP PAD
I I I
I
OCXXX)47910
© 2023 Navistar, Inc. All rights reserved. All marks are trademarks of their respective owners. 10
UNITED STATES AND POSSESSIONS
The National Traffic and Motor Vehicle Safety Act, as amended, provides that
each vehicle that is subject to a vehicle recall campaign must be adequately
repaired within a reasonable time after the owner has tendered it for repair. A
failure to adequately repair within 60 days after a tender of a vehicle is prima
facie evidence of failure to repair within a reasonable time. If the condition is not
adequately repaired within 60 days, the owner may be entitled to replacement
with an identical or reasonable equivalent vehicle at no charge, or to a refund of
the purchase price less a reasonable allowance for depreciation.
Dealers must correct all vehicles subject to this campaign at no charge to the
owner, regardless of mileage, age of vehicle, or ownership, from this time
forward.
Dealers should proceed immediately to make necessary correction to units in
inventory. Federal law prohibits a dealer from delivering under a sale or lease, a
new motor vehicle or any new or used item of motor vehicle equipment (including
a tire) covered by the notification of a recall until the defect or noncompliance is
remedied .
. Dealers must make every effort to promptly schedule an appointment with each
owner to repair his or her vehicle as soon as possible. However, consistent with
the customer notification, dealers are expected to complete the repairs on the
mutually agreed upon service date.
Dealers involved in the recall process will be furnished a listing of owner names
and addresses to enable them to follow up with owners and have the vehicles
corrected. Use of this listing must be limited to this campaign because the list
may contain information obtained from state motor vehicle registration records,
and the use of such motor vehicle registration data for purposes other than this
campaign is a violation of law in several states.
CANADA
Dealers must correct all vehicles subject to this campaign at no charge to the
owner, regardless of mileage, age of vehicle, or ownership, from this time
forward.
Dealers should proceed immediately to make necessary correction to units in
inventory. All inventory vehicles subject to this recall campaign must be
corrected prior to sale, transfer or delivery. If vehicles have been sold or
transferred and you are in receipt of Customer Notification Letters and
Authorization for Recall Service cards for those vehicles, the transfer location or
customer must be notified immediately from your dealer location.
VEHICLE RECALL 23507
© 2023 Navistar, Inc. All rights reserved. All marks are trademarks of their respective owners. 11
Dealers must make every effort to promptly schedule an appointment with each
owner to repair his or her vehicle as soon as possible. However, consistent with
the customer notification, dealers are expected to complete the repairs on the
mutually agreed upon service date.
Dealers involved in the recall process will be furnished a listing of owner names
and addresses to enable them to follow up with owners and have the vehicles
corrected. Use of this listing must be limited to this campaign because the list
may contain information obtained from state motor vehicle registration records,
and the use of such motor vehicle registration data for purposes other than this
campaign is a violation of law in several states.
EXPORT
Export Distributors should proceed immediately to make necessary correction to
units in inventory. All inventory vehicles subject to this recall campaign must be
corrected prior to sale, transfer or delivery. If vehicles have been sold or
transferred and you are in receipt of Customer Notification Letters and
Authorization for Recall Service cards for those vehicles, the transfer location or
customer must be notified immediately from your distributor location.
Export Distributors are to submit warranty claims in the usual manner making
reference to this recall number.
Export Distributors are expected to provide full cooperation and follow-up with
respect to this important subject matter. If you have any questions or need
further assistance, please contact the Regional Service Manager at your regional
office.
NAVISTAR, INC.
VEHICLE RECALL 23507
© 2023 Navistar, Inc. All rights reserved. All marks are trademarks of their respective owners. 12

**************************************************************************************************************

NOV 14 2023
Compliance Dept
SUBJECT: SAFETY RECALL
23507R3
November, 2023
Grille surround on certain 2020 thru 2024
International® HX® Series trucks built 03/13/2019
thru 02/28/2023
CUSTOMER LETTER
Print ready (PDF file) copy of the Customer Letter
REVISION STATEMENT
Parts and Service procedure have been updated to begin replacing grille
surrounds on HX615 and HX620 series trucks.
DEFECT DESCRIPTION
Over time, the grille surround may come loose from the eight mounting brackets
that secure it to the hood. This may cause the grille surround to separate from
the truck. A grille surround that separates from the truck and falls to the roadway
while the vehicle is in operation can increase the risk of a vehicle crash that may
result in property damage, personal injury, or death.
MODELS INVOLVED
NOTE: For HX615 and the HX620 vehicles, a new grille surround is
available at this time.
NOTE: For HX520 vehicles, a new grille surround is NOT available at this
time. When a new grille surround is available, this document will be
updated, and customers will be notified. Until that time, if the grille
surround on an HX520 is found loose at the time of write-up, the interim
repair should be completed. There are no inspection-only claims.
This safety recall involves certain 2020 thru 2024 International® HX® Series
trucks built 03/13/2019 thru 02/28/2023.
VEHICLE RECALL 23507
@2023 Navistar, Inc. All rights reserved. All marks are trademarks of their respective owners. 1
ELIGIBILITY
This procedure applies ONLY to vehicles marked in the International® Service
Portal5M with Safety Recall 23507. Also complete any other open campaigns
listed on the Service Portal at this time.
SPECIAL TOOLS FOR HX520 ONLY
Tool Description Part Number
Rivet Gun Rivet Gun with mandrel for 3/16-inch N/A
diameter rivets (manual or pneumatic)
#11 Drill Bit Drill Bit N/A
Black Permanent Black Permanent Marker N/A
Marker
Pneumatic Grinder Pneumatic Grinder N/A
Pneumatic Rotary Pneumatic Rotary Sanding Wheel N/A
SandinQ Wheel
PARTS INFORMATION
CAUTION! To prevent damage to property, the rivets specified for this
repair must be used and NOT substituted with any other type. These rivets
are available from the sources listed in the table below.
HX615 / HX620 Parts Table
Part Number I Part Description I Quantity
8900370R91 I Grille Surround HX615 / HX620 I 1
HX520 Parts Table
Part Number Parts Description Quantitv
Fastenal P/N: 0126282 Rivet: 3/16-in Dia. Stainless Steel 28
Grainger P/N: 3ZKT1 w/0.125-in-0.25-in Grip Range
McMaster-Carr P/N:
97525A490
NPN / Source Locally Heavy Double-Sided Tape As
Needed
VEHICLE RECALL 23507
© 2023 Navistar, Inc. All rights reserved. All marks are trademarks of their respective owners. 2
SERVICE PROCEDURE
WARNING! To prevent personal mJury and / or death, or damage to
property, park vehicle on hard flat surface, turn the engine off, set the
parking brake and install wheel chocks to prevent the vehicle from moving
in either direction.
WARNING! To prevent personal injury and/ or death, always wear safe eye
protection when performing vehicle maintenance.
WARNING! To prevent personal injury and / or death, or damage to
property, allow engine/ vehicle components to cool before servicing.
WARNING! To prevent personal injury and I or death, or damage to
property, keep flames or sparks away from vehicle and do not smoke while
servicing the vehicle’s batteries. Batteries expel explosive gases.
1. Park vehicle on flat surface.
2. Shift transmission to Park or Neutral and set parking brake.
3. Turn vehicle ignition to Key OFF position.
4. Install wheel chocks.
Instructions to Replace Grille Surround on HX615 and HX620
Series Trucks
5. Unlatch and open hood.
VEHICLE RECALL 23507
© 2023 Navistar, Inc. All rights reserved. All marks are trademarks of their respective owners. 3
2
____ ……. –
·-·—–·-
…. -, …. ~
~
,_… , ,,. … —-~-… •~ .,.. 3
4
00004 n92 9
Figure 1. HX615 and HX620 Models Grille Surround Removal
1. MS palnut (2)
2. Grille assembly
3. MS Keps nut (8)
4. Grille surround
6. Remove eight M8 Keps nuts (Figure 1, Item 3) from the back of grille surround
{Figure 1, Item 4 ). Save MB Keps nuts for reuse.
7. Remove grille assembly (Figure 1, Item 2) from truck by pushing inward and
rotating 90 degrees to remove it through hood opening.
8. Remove two MB palnuts (Figure 1, Item 1) from stud by rotating them
counterclockwise. Save MB palnuts for reuse.
9. Remove and discard grille surround (Figure 1, Item 4 ).
10. With hood in open position, position new grille surround (Figure 1, Item 4)
into place on hood and install two MB palnuts (Figure 1, Item 1 ).
11. Install grille assembly (Figure 1, Item 2) inserting it through hood front
opening, rotate grille 90 degrees, and position into place.
12. Install eight MB Keps nuts. Tighten nuts to 5.3 – 6.6 lb-ft (7.2 – 9.0 N·m).
13. Close and latch hood.
VEHICLE RECALL 23507
© 2023 NavtStar, Inc. All rights reserved. All marks are trademarks of their respective owners. 4
14. Remove wheel chocks.
Instructions for Grille Surround interim repair for HX520 Series
Trucks
NOTE: ONLY grille surrounds found loose shall receive the interim repair.
There should be no inspection-only claims so that the recall stays open
should the grille surround become loose prior to final remedy.
15. Before assigning a technician to this recall, check the grille surround to verify
it requires the interim repair. Using hand force, pull the grille surround away
from the hood to see if one or more brackets have de-bonded from the grille
surround.
a. If one or more areas of the grille surround moves, assign a technician and
have them proceed to Step 16.
b. If the grille surround does not move, then no repair is required at this
time. Proceed to Step 28.
2
OOOCM71930
Figure 2. HX520 Model Grille Surround Removal
1. Grille surround
2. M8 prevailing torque nut (8)
3. M8 Torx®bolts (8)
4. Grille assembly
NOTE: The eight MS Tone® bolts must be returned to their original positions
when grille assembly is installed. (MB Tone® bolts are different in length.)
16. With hood closed, remove eight MB Tone® bolts (Figure 2, Item 3) from
center of grille assembly (Figure 2, Item 4). Save Tone® bolts for reuse.
VEHICLE RECALL 23507
© 2023 Navistar, Inc. All rights reserved. All marks are trademarks of their respective owners. 5
17. Remove grille assembly (Figure 2, Item 4) and safely set aside.
18. Remove eight MB prevailing torque nuts (Figure 2, Item 2) from back of grille
surround (Figure 2, Item 1 ). Save nuts for reuse.
19. Remove grille surround (Figure 2, Item 1) from hood and place face down on
a clean, protected workbench.
NOTE: All support brackets must be repaired whether they are still
attached, loose on one pad and not fully detached, or fully detached.
20. Determine condition of support bracket mounting.
21. For each support bracket that is loose on one pad but not fully detached,
perform the following:
a. Press the loose pad back down to the original location on the back side of
the grille surround.
b. Using heavy double-sided tape or a clamp, hold support bracket in place
on grille surround for drilling and riveting.
22. For each support bracket that is fully detached from the grille surround,
perform the following:
a. Using pneumatic grinder with rotary sanding wheel, clean rust and I or
corrosion from both the grille surround and the mounting surface of the
support brackets.
b. Apply a 2-inch strip of heavy double-sided tape to each pad of the
mounting brackets.
c. Install the detached mounting brackets into their correct location on the
hood.
i. For HX520 Series trucks, install eight MB prevailing torque nuts to hold
the mounting brackets in place. Install M8 prevailing torque nuts to
hold each separated mounting bracket to keep it in place.
d. Once all brackets are installed and secured, install grille surround onto
the hood.
e. Apply hand pressure at each location of grille surround. Use the palm of
one hand on the grille surround and the fingers of your other hand on the
back side of bracket.
VEHICLE RECALL 23507
© 2023 Navistar, Inc. All rights reserved. All marks are trademarks of their respective owners. 6
f. Once pressure has been applied to each location, remove nuts installed
in Step 22. c. i, and remove grille surround.
23. Drill 28 #11 diameter holes from back side.
a. Refer to Figure 2 for HX520 Series trucks.
24. Once all holes have been drilled, turn grille surround over, deburr each hole
taking care not to increase the diameter, and install rivets from front side in
all 28 locations.
25. Once all rivets have been installed, inspect each rivet for correct installation.
26. With hood in closed position, install grille surround (Figure 2, Item 1) and
position on hood and install eight prevailing torque nuts (Figure 2, Item 2).
27. Position grille assembly (Figure 2, Item 4) into place and install eight M8
Tor><® bolts (Figure 2, Item 3).
28. Remove wheel chocks.
END OF SERVICE PROCEDURE
LABOR INFORMATION
HX615 / HX620
Operation Number Description
A40-23507-6 Replace Grille Surround
HX520
Operation Number Description
A40-23507-1 R&R Grille Surround, Drill & Install Rivets
A40-23507-2 Reattach One or Two Brackets
A40-23507-3 Reattach Three or Four Brackets
A40-23507-4 Reattach Five Brackets
A40-23507-5 Reattach Six Brackets
VEHICLE RECALL 23507
Time
0.5 hrs
Time
0.8 hrs
0.9 hrs
1.0 hrs
1.1 hrs
1.2 hrs
© 2023 Navistar, Inc. All rights reserved. All marks are trademarks of their respective owners. 7
CAMPAIGN IDENTIFICATION LABEL
Each vehicle corrected in accordance with this
campaign must be marked with a CTS-1075
Campaign Identification Label.
Complete the label and attach on a clean surface next
to the vehicle identification number (VIN) plate.
ADMINISTRATIVE/ DEALER RESPONSIBILITIES
WARRANTY CLAIMS
COMPLETED
Service Location Code ‘
Warranty claim expense is to be charged to Warranty. Claims are to be
submitted in the normal manner, making reference to Safety Recall 23507.
Section 7 of the Warranty Policy and Procedures Manual contains further
information related to the submission and processing of AFC / Recall claims.
As with all claim submissions, items acquired locally must be submitted in the
“Other Charges” tab. The cost of any bulk items (such as a bag of cable tie
straps, roll of wire, barrel of oil, or tube of silicone) should be prorated for the cost
of the individual pieces/ amount used during each repair.
GROUP – Enter nu mber
NOUN – Leave b lank .;:
+- I
GROUP
I I
–
C (CAUSE)- Ente r either 1, 2, 3, (See below)
1. Inspected (No repair required).
2. Inspected and repaired
3. Defective part from parts stock. –
WARRANTY – tWa rranty Code) Enter 40
TYPE PART – En
PAO – Enter t)()
ter P for type part causing failure. ~
,;:
VEHICLE RECALL 23507
NOUN C WARR. TP PAD
I I I
I
~ Jll’9’0
© 2023 Navistar, Inc. All rights reseived. All marks are trademarks of their respective owners. 8
UNITED STATES AND POSSESSIONS
The National Traffic and Motor Vehicle Safety Act, as amended, provides that
each vehicle that is subject to a vehicle recall campaign must be adequately
repaired within a reasonable time after the owner has tendered it for repair. A
failure to adequately repair within 60 days after a tender of a vehicle is prima
facie evidence of failure to repair within a reasonable time. If the condition is not
adequately repaired within 60 days, the owner may be entitled to replacement
with an identical or reasonable equivalent vehicle at no charge, or to a refund of
the purchase price less a reasonable allowance for depreciation.
Dealers must correct all vehicles subject to this campaign at no charge to the
owner, regardless of mileage, age of vehicle, or ownership, from this time
forward.
Dealers should proceed immediately to make necessary correction to units in
inventory. Federal law prohibits a dealer from delivering under a sale or lease, a
new motor vehicle or any new or used item of motor vehicle equipment (including
a tire) covered by the notification of a recall until the defect or noncompliance is
remedied .
. Dealers must make every effort to promptly schedule an appointment with each
owner to repair his or her vehicle as soon as possible. However, consistent with
the customer notification, dealers are expected to complete the repairs on the
mutually agreed upon service date.
Dealers involved in the recall process will be furnished a listing of owner names
and addresses to enable them to follow up with owners and have the vehicles
corrected. Use of this listing must be limited to this campaign because the list
may contain information obtained from state motor vehicle registration records,
and the use of such motor vehicle registration data for purposes other than this
campaign is a violation of law in several states.
CANADA
Dealers must correct all vehicles subject to this campaign at no charge to the
owner, regardless of mileage, age of vehicle, or ownership, from this time
forward.
Dealers should proceed immediately to make necessary correction to units in
inventory. All inventory vehicles subject to this recall campaign must be
corrected prior to sale, transfer or delivery. If vehicles have been sold or
transferred and you are in receipt of Customer Notification Letters and
Authorization for Recall Service cards for those vehicles, the transfer location or
customer must be notified immediately from your dealer location.
VEHICLE RECALL 23507
e 2023 Navistar, Inc. All rights reserved. All marks are trademarks of their respective owners. 9
Dealers must make every effort to promptly schedule an appointment with each
owner to repair his or her vehicle as soon as possible. However, consistent with
the customer notification, dealers are expected to complete the repairs on the
mutually agreed upon service date.
Dealers involved in the recall process will be furnished a listing of owner names
and addresses to enable them to follow up with owners and have the vehicles
corrected. Use of this listing must be limited to this campaign because the list
may contain information obtained from state motor vehicle registration records,
and the use of such motor vehicle registration data for purposes other than this
campaign is a violation of law in several states.
EXPORT
Export Distributors should proceed immediately to make necessary correction to
units in inventory. All inventory vehicles subject to this recall campaign must be
corrected prior to sale, transfer or delivery. If vehicles have been sold or
transferred and you are in receipt of Customer Notification Letters and
Authorization for Recall Service cards for those vehicles, the transfer location or
customer must be notified immediately from your distributor location.
Export Distributors are to submit warranty claims in the usual manner making
reference to this recall number.
Export Distributors are expected to provide full cooperation and follow-up with
respect to this important subject matter. If you have any questions or need
further assistance, please contact the Regional Service Manager at your regional
office.
NAVISTAR, INC.
VEHICLE RECALL 23507
@ 2023 Navistar, Inc. All rights reserved. All marks are trademarks of their respective owners. 10

**************************************************************************************************************

Navistar, Inc.
2701 Navistar Drive
Usie, IL 60532 USA
navistar.com
IMPORTANT SAFETY RECALL 23507
NHTSA RECALL NO. 23V-170
This notice applies to your vehicle identified on the
enclosed card.
Dear INTERNATIONAL• Customer,
This notice is sent to you in accordance with the
requirements of the National Traffic and Motor Vehicle
Safety Act.
Navistar has decided that a defect which relates to motor
vehicle safety exists in certain 2020 thru 2024 HX® series
trucks built 03/13/2019 thru 02/28/2023.
REASON FOR THIS RECALL
Over time, the grille surround may become loose from the
eight (8) mounting brackets that secure the grille surround
to the hood and could eventually cause the grille surround
to separate from the truck.
RISK TO MOTOR VEHICLE SAFETY
A grille surround that separates from the truck while in
operation can increase the risk of a vehicle crash that may
result in personal injury or property damage.
DEFECT REMEDY
The repair will involve installing a new grille surround with
an updated mounting bracket design. Parts are available to
repair HX615® and HX620® vehicles at this time.
Authorized repair locations have these parts and
instructions to repair your vehicle. The repair will be
performed free of charge and take approximately 45
minutes to complete.
Parts are only available to repair HX615® and HX620®
vehicles.
ACTIONS YOU SHOULD TAKE
If you own this vehicle, please schedule an appointment
with any Authorized repair center to have your vehicle
repaired at no cost to you. You can find your nearest
dealer by using the dealer locator at
https:l/www.internationaltrucks.com/dealer-locator or by
~&□ ~[§[ID
NOV 2 1 2023
By: f.:?-:’1/..{:d#.r.£. A NAVISTAR COMPANY
NOVEMBER 2023
calling 1-800-448-7825 or find the nearest love’s center at
https:l/www.loves.com .
*love’s and Speedco locations in Texas cannot perform
warranty services.
If you have already paid for repairs prior to this notice
that corrected this defect, you may be eligible for
reimbursement of certain repair expenses if they occurred
03/16/2023 thru 12/02/2023. Present your original repair
paperwork and proof of payment to any
INTERNATIONAL® dealer and your eligibility will be
reviewed. You may also submit a claim using the enclosed
Request for Reimbursement card.
If you are the lessor of this vehicle, please forward a
copy of this notice to the lessee within ten days to comply
with federal regulations.
If you do not own this vehicle, please fill out and return
mail the enclosed card so that you will not be contacted
again about this recall.
IF YOU NEED FURTHER ASSISTANCE
If you believe that Navistar has failed to remedy the defect
without charge or within a reasonable time, please follow
the procedure described in the Owner Assistance Guide
section in your Owner’s Manual or call toll free 1-800-448-
7825.
You may also submit a complaint to the Administrator,
National Highway Traffic Safety Administration, 1200 New
Jersey Ave, SE, Washington, DC 20590; or call the toll
free Vehicle Safety Hotline at 1-888-327-4236 (TTY: 1-800-
424-9153); or go to http://www.safercar.gov.
Navistar requests your prompt attention and patience
regarding the correction of this defect and apologizes for
any inconvenience this may cause you.
Navistar, Inc.

**************************************************************************************************************

OMB Control No.: 2127-0004
Part 573 Safety Recall Report 23V-170
The information contained in this report was submitted pursuant to 49 CFR §573
Manufacturer Name : Submission Date :
Navistar, Inc. OCT 25, 2023 NHTSA Recall No. : 23V-170 Manufacturer Recall No. : 23507 Manufacturer Information :
Manufacturer Name : Navistar, Inc.
Address : 2701 Navistar Drive
Lisle IL 60532 Company phone : 331-332-1590
Population :
Number of potentially involved : 5,769 Estimated percentage with defect : 100 %
Vehicle Information : Vehicle 1 : 2020-2024 International HX
Vehicle Type : BUSES, MEDIUM & HEAVY VEHICLES Body Style : OTHER Power Train : DIESEL
Descriptive Information : • The suspect population is identified by the models of the vehicle, HX520 and HX620.
• The inclusive dates of manufacture were determined by when there was a design change to the grille surround.
• The vehicles in the suspect population were built with a steel grille surround; all other models use a non-metallic grille surround.
There are 5769 HX series trucks in the suspect population.
Production Dates : MAR 13, 2019 – FEB 28, 2023
VIN Range 1 : Begin : NR End : NR Not sequential Description of Defect :
Description of the Defect : The grille surround is attached to eight (8) mounting brackets by a bonding material. Over time, corrosion can develop between the two dissimilar metal components and cause the bonding material to lose adhesion, resulting in the grille surround coming loose one bracket at a time and could cause the grille surround to separate from the truck.
FMVSS 1 : NR FMVSS 2 : NR
Description of the Safety Risk : A grille surround that separates from the vehicle and falls to the roadway
while the vehicle is in operation, can increase the risk of a vehicle crash that may result in property damage, personal injury or death. To date, there have been no reported crashes for this issue. Description of the Cause : Insufficient plating in the area where the eight (8) mounting brackets are Part 573 Safety Recall Report 23V-170 Page 2 Identification of Any Warning
that can Occur : attached to the grille surround results in a small area of bare steel susceptible to corrosion over time.
Driver would hear the grille surround rattling when the vehicle is in operation and should notice that grille surround is not flush against the hood during a pre-trip walk around inspection. Involved Components : Component Name 1 : Grille Surround Component Description : Surround Assembly
Component Part Number : International P/N 4059254C95 and 4160590C93 Supplier Identification : Component Manufacturer
Name : Lincoln Industries Address : 600 West E Street
Lincoln Nebraska 68522
Country : United States Chronology :
• 01/15/2023 – Navistar Engineering received communication of this issue from Service Engineering.
• 01/15/2013 – Navistar Engineering initiates an investigation into grille surround supplier.
• 01/26/2023 – Navistar Engineering and supplier reviews the validation results from when the attachment methods of the mounting brackets to the surround changed from spot welding to adhesive.
• 02/13/2023 – An analysis of a loose grille surround was completed and determined to have insufficient plating of all eight mounting brackets.
• 02/14/2023 – Navistar Engineering and Product Compliance meet to review the issue and determine the possible vehicle level impact to the HX series trucks.
• 2/24/2023 – Navistar finishes a study of warranty claims to determine how widespread this issue may be. Seven warranty claims received on 05/26/2021, 12/20/2021, 02/24/2022, 05/27/2022, 08/19/2022, 09/29/2022/ and 02/01/2023 were found to have concerns, there are no Field Reports, Customer Complaints or death/injury claims found for this issue. For additional warranty details, refer to chart at end of chronology.
• 03/08/2023 – Engineering and Product Compliance finalize the suspect population.
• 03/09/2023 – Navistar declares a Safety Recall.
• 03/24/2023 – Navistar removes vehicles quarantined at the plants from the suspect population. Warranty Claim Summary
VINs Vehicle Prod Date Warranty Claim Date The information contained in this report was submitted pursuant to 49 CFR §573 Part 573 Safety Recall Report 23V-170
Page 3
The information contained in this report was submitted pursuant to 49 CFR §573
LN305983 05/07/2019 05/26/2021 LN146563 09/03/2019 12/20/2021 MN632819 09/08/2020 02/24/2022 LN317203 06/24/2019 05/27/2022 NN303289 11/17/2021 08/19/2022 NN609502 03/09/2021 09/29/2022 MN548866 01/30/2020 02/01/2023
Description of Remedy :
Description of Remedy Program : • The remedy will involve replacing grille surround on 5,769 units
plus those that will be built prior to containment.
• Navistar’s plan for reimbursement of pre-notification remedies, on file with NHTSA and dated 05/06/2022, applies and reimbursement instructions will be included in the customer notification.
• An Interim notice will be mailed to affected customers instructing them to periodically inspect their grille surround and repair if necessary. How Remedy Component Differs from Recalled Component :
Identify How/When Recall Condition was Corrected in Production : The remedy grille surround will be assembled using a new process to attach the brackets.
03/15/2023 – Navistar contains the issue in manufacturing by issuing a stop ship order.
Recall Schedule :
Description of Recall Schedule : • It is estimated that the HX620 Customer final remedy notification
letter will be mailed by 12/01/2023 and the HX520 Customer final remedy notification letter will be mailed by 02/01/2024.
• It is estimated that the 23507 dealer interim instructions will be updated for HX620 final remedy by 12/01/2023 and updated for HX520 dealer final remedy by 02/01/2024.
Planned Dealer Notification Date : DEC 01, 2023 – FEB 01, 2024
Planned Owner Notification Date : DEC 01, 2023 – FEB 01, 2024
* NR – Not Reported

**************************************************************************************************************

OMB Control No.: 2127-0004
Part 573 Safety Recall Report 23V-170
The information contained in this report was submitted pursuant to 49 CFR §573
Manufacturer Name : Submission Date :
Navistar, Inc. MAR 16, 2023 NHTSA Recall No. : 23V-170 Manufacturer Recall No. : 23507 Manufacturer Information :
Manufacturer Name : Navistar, Inc.
Address : 2701 Navistar Drive
Lisle IL 60532 Company phone : 331-332-1590
Population :
Number of potentially involved : 5,808 Estimated percentage with defect : 100 %
Vehicle Information : Vehicle 1 : 2020-2024 International HX
Vehicle Type : BUSES, MEDIUM & HEAVY VEHICLES Body Style : OTHER Power Train : DIESEL
Descriptive Information : • The suspect population is identified by the models of the vehicle, HX520 and HX620.
• The inclusive dates of manufacture were determined by when there was a design change to the grille surround.
• The vehicles in the suspect population were built with a steel grille surround; all other models use a non-metallic grille surround.
There are 5808 HX series trucks in the suspect population.
Production Dates : MAR 13, 2019 – FEB 28, 2023
VIN Range 1 : Begin : NR End : NR Not sequential Description of Defect :
Description of the Defect : The grille surround is attached to eight (8) mounting brackets by a bonding material. Over time, corrosion can develop between the two dissimilar metal components and cause the bonding material to lose adhesion, resulting in the grille surround coming loose one bracket at a time and could cause the grille surround to separate from the truck.
FMVSS 1 : NR FMVSS 2 : NR
Description of the Safety Risk : A grille surround that separates from the vehicle and falls to the roadway
while the vehicle is in operation, can increase the risk of a vehicle crash that may result in property damage, personal injury or death. To date, there have been no reported crashes for this issue. Description of the Cause : Insufficient plating in the area where the eight (8) mounting brackets are Part 573 Safety Recall Report 23V-170 Page 2 Identification of Any Warning
that can Occur : attached to the grille surround results in a small area of bare steel susceptible to corrosion over time.
Driver would hear the grille surround rattling when the vehicle is in operation and should notice that grille surround is not flush against the hood during a pre-trip walk around inspection. Involved Components : Component Name 1 : Grille Surround Component Description : Surround Assembly
Component Part Number : International P/N 4059254C95 and 4160590C93 Supplier Identification : Component Manufacturer
Name : Lincoln Industries Address : 600 West E Street
Lincoln Nebraska 68522
Country : United States Chronology :
• 01/15/2023 – Navistar Engineering received communication of this issue from Service Engineering.
• 01/15/2013 – Navistar Engineering initiates an investigation into grille surround supplier.
• 01/26/2023 – Navistar Engineering and supplier reviews the validation results from when the attachment methods of the mounting brackets to the surround changed from spot welding to adhesive.
• 02/13/2023 – An analysis of a loose grille surround was completed and determined to have insufficient plating of all eight mounting brackets.
• 02/14/2023 – Navistar Engineering and Product Compliance meet to review the issue and determine the possible vehicle level impact to the HX series trucks.
• 2/24/2023 – Navistar finishes a study of warranty claims to determine how widespread this issue may be.
• 03/08/2023 – Engineering and Product Compliance finalize the suspect population.
• 03/09/2023 – Navistar declares a Safety Recall. The information contained in this report was submitted pursuant to 49 CFR §573 Part 573 Safety Recall Report 23V-170
Page 3
The information contained in this report was submitted pursuant to 49 CFR §573
Description of Remedy :
Description of Remedy Program : • The remedy will involve replacing grille surround on 8,120 units
plus those that will be built prior to containment.
• Navistar’s plan for reimbursement of pre-notification remedies, on file with NHTSA and dated 05/06/2022, applies and reimbursement instructions will be included in the customer notification.
• An Interim notice will be mailed to affected customers instructing them to periodically inspect their grille surround and repair if necessary. How Remedy Component Differs from Recalled Component :
Identify How/When Recall Condition was Corrected in Production : The remedy grille surround will be assembled using a new process to attach the brackets.
03/15/2023 – Navistar contains the issue in manufacturing by issuing a stop ship order. Recall Schedule :
Description of Recall Schedule : It is estimated that the Customer and Dealer notification letters will be
mailed by 05/15/2023.
Planned Dealer Notification Date : MAY 15, 2023 – MAY 15, 2023
Planned Owner Notification Date : MAY 15, 2023 – MAY 15, 2023
* NR – Not Reported

**************************************************************************************************************

OMB Control No.: 2127-0004
Part 573 Safety Recall Report 23V-170
The information contained in this report was submitted pursuant to 49 CFR §573
Manufacturer Name : Submission Date :
Navistar, Inc. MAR 24, 2023 NHTSA Recall No. : 23V-170 Manufacturer Recall No. : 23507 Manufacturer Information :
Manufacturer Name : Navistar, Inc.
Address : 2701 Navistar Drive
Lisle IL 60532 Company phone : 331-332-1590
Population :
Number of potentially involved : 5,769 Estimated percentage with defect : 100 %
Vehicle Information : Vehicle 1 : 2020-2024 International HX
Vehicle Type : BUSES, MEDIUM & HEAVY VEHICLES Body Style : OTHER Power Train : DIESEL
Descriptive Information : • The suspect population is identified by the models of the vehicle, HX520 and HX620.
• The inclusive dates of manufacture were determined by when there was a design change to the grille surround.
• The vehicles in the suspect population were built with a steel grille surround; all other models use a non-metallic grille surround.
There are 5769 HX series trucks in the suspect population.
Production Dates : MAR 13, 2019 – FEB 28, 2023
VIN Range 1 : Begin : NR End : NR Not sequential Description of Defect :
Description of the Defect : The grille surround is attached to eight (8) mounting brackets by a bonding material. Over time, corrosion can develop between the two dissimilar metal components and cause the bonding material to lose adhesion, resulting in the grille surround coming loose one bracket at a time and could cause the grille surround to separate from the truck.
FMVSS 1 : NR FMVSS 2 : NR
Description of the Safety Risk : A grille surround that separates from the vehicle and falls to the roadway
while the vehicle is in operation, can increase the risk of a vehicle crash that may result in property damage, personal injury or death. To date, there have been no reported crashes for this issue. Description of the Cause : Insufficient plating in the area where the eight (8) mounting brackets are Part 573 Safety Recall Report 23V-170 Page 2 Identification of Any Warning
that can Occur : attached to the grille surround results in a small area of bare steel susceptible to corrosion over time.
Driver would hear the grille surround rattling when the vehicle is in operation and should notice that grille surround is not flush against the hood during a pre-trip walk around inspection. Involved Components : Component Name 1 : Grille Surround Component Description : Surround Assembly
Component Part Number : International P/N 4059254C95 and 4160590C93 Supplier Identification : Component Manufacturer
Name : Lincoln Industries Address : 600 West E Street
Lincoln Nebraska 68522
Country : United States Chronology :
• 01/15/2023 – Navistar Engineering received communication of this issue from Service Engineering.
• 01/15/2013 – Navistar Engineering initiates an investigation into grille surround supplier.
• 01/26/2023 – Navistar Engineering and supplier reviews the validation results from when the attachment methods of the mounting brackets to the surround changed from spot welding to adhesive.
• 02/13/2023 – An analysis of a loose grille surround was completed and determined to have insufficient plating of all eight mounting brackets.
• 02/14/2023 – Navistar Engineering and Product Compliance meet to review the issue and determine the possible vehicle level impact to the HX series trucks.
• 2/24/2023 – Navistar finishes a study of warranty claims to determine how widespread this issue may be. Seven warranty claims received on 05/26/2021, 12/20/2021, 02/24/2022, 05/27/2022, 08/19/2022, 09/29/2022/ and 02/01/2023 were found to have concerns, there are no Field Reports, Customer Complaints or death/injury claims found for this issue. For additional warranty details, refer to chart at end of chronology.
• 03/08/2023 – Engineering and Product Compliance finalize the suspect population.
• 03/09/2023 – Navistar declares a Safety Recall.
• 03/24/2023 – Navistar removes vehicles quarantined at the plants from the suspect population. Warranty Claim Summary
VINs Vehicle Prod Date Warranty Claim Date The information contained in this report was submitted pursuant to 49 CFR §573 Part 573 Safety Recall Report 23V-170
Page 3
The information contained in this report was submitted pursuant to 49 CFR §573
LN305983 05/07/2019 05/26/2021 LN146563 09/03/2019 12/20/2021 MN632819 09/08/2020 02/24/2022 LN317203 06/24/2019 05/27/2022 NN303289 11/17/2021 08/19/2022 NN609502 03/09/2021 09/29/2022 MN548866 01/30/2020 02/01/2023
Description of Remedy :
Description of Remedy Program : • The remedy will involve replacing grille surround on 5,769 units
plus those that will be built prior to containment.
• Navistar’s plan for reimbursement of pre-notification remedies, on file with NHTSA and dated 05/06/2022, applies and reimbursement instructions will be included in the customer notification.
• An Interim notice will be mailed to affected customers instructing them to periodically inspect their grille surround and repair if necessary. How Remedy Component Differs from Recalled Component :
Identify How/When Recall Condition was Corrected in Production : The remedy grille surround will be assembled using a new process to attach the brackets.
03/15/2023 – Navistar contains the issue in manufacturing by issuing a stop ship order. Recall Schedule :
Description of Recall Schedule : It is estimated that the Customer and Dealer notification letters will be
mailed by 05/15/2023.
Planned Dealer Notification Date : MAY 15, 2023 – MAY 15, 2023
Planned Owner Notification Date : MAY 15, 2023 – MAY 15, 2023
* NR – Not Reported

**************************************************************************************************************

SEOCONTENT-END
