21E009 Cummins X15 Diesel Engines Flywheel Capscrews

February 4, 2021 NHTSA CAMPAIGN NUMBER: 21E009000

Flywheel Capscrews Not Tightened Properly

A detached flywheel can cause loss of drive power, increasing the risk of a crash. Additionally, driveline pieces may be ejected from the engine compartment, increasing the risk of injury.



NHTSA Campaign Number: 21E009

Manufacturer Cummins, Inc.

Components ENGINE

Potential Number of Units Affected 251



Summary

Cummins, Inc. (Cummins) is recalling certain X15 diesel engines, part number D103109BX03. The capscrews that attach the flywheel to the crankshaft may have been improperly torqued, allowing the flywheel to detach.



Remedy

Cummins will notify owners, and dealers will properly torque the capscrews and inspect for possible damage and, if necessary, repair any damage found, free of charge. The recall began March 29, 2021. Owners may contact Cummins customer service at 1-800-286-6467. Cummin’s number for this recall is C2402.



Notes

Owners may also contact the National Highway Traffic Safety Administration Vehicle Safety Hotline at 1-888-327-4236 (TTY 1-800-424-9153), or go to www.safercar.gov.



---

*** IMPORTANT SAFETY RECALL ***
NHTSA Recall No. 21E-009



February 5, 2021



Jim Bingaman
Peterbilt Product Safety Manager
3200 Airport Rd
PO Box 550
Denton, TX 76202



Dear Cummins OEM Customer:



We are writing to inform you that Cummins Inc. has determined that a safety-related defect exists in certain X15 engines that were manufactured between October 27, 2020 and January 11, 2021.  Cummins has initiated a recall of the subject engines.  Our records indicate that some of these engines have been shipped to you.



A copy of Cummins’ initial Part 573 Defect Notification report is enclosed.  This notification was submitted to the National Highway Traffic Safety Administration (NHTSA) on February 4, 2021.  As more fully described in the Defect Notification, the engine flywheel may be susceptible to detaching from the crankshaft, leading to loss of motive power, which may increase the risk of a crash.  Additionally, driveline pieces may be ejected from the engine compartment, which may increase the risk of personal injury.



Enclosed is a list of Engine Serial Numbers for affected engines that our records indicate were shipped to your plants.  For engines installed in vehicles that have left your control, we encourage you to make a safety defect determination in accordance with 49 USC 30118 et seq. and, as appropriate, to submit a Defect Notification to NHTSA in accordance with 49 CFR Part 573.  Cummins will conduct the recall, including notifying owners pursuant to 49 CFR Part 577, performing the remedy, and submitting quarterly status reports to NHTSA. Cummins is requesting that you provide the associated vehicle model identification, VINs and owner contact information to facilitate owner notification.  Please work with your Cummins account team leader to ensure that the requested information is provided to Cummins as soon as possible.



For engines/vehicles that are still in your inventory, please contact the Customer Quality Assurance representative at the Jamestown Engine Plant to arrange for repairs, as necessary.  Please note that Federal law prohibits delivery of these engines, or vehicles equipped with these engines, under a sale or lease until this condition has been remedied.



Cummins will conduct a safety campaign to properly torque the subject capscrews and inspect for possible damage and, if necessary, repair the damage.



Cummins apologizes for this inconvenience, but we are initiating this action in the interest of our customers’ safety and satisfaction with our products.  Thank you for your assistance.



Please confirm receipt of this communication.



Sincerely,



Steve Collins

Cummins OEM Service and Quality Leader



Enclosures:

1. Cummins Part 573 Defect Notification
2. List of Engine Serial Numbers.



---

Warranty Field Campaign

Campaign Number: c2402	Revision:	Released Date: 25-Feb-2021
ISX15 CM2250 SN and X15 CM2450 X124B/X134B Flywheel Capscrew Retorque Safety Campaign		Expiration Date (U.S. and Canada): 25-Feb-2046
		Expiration Date (International): 25-Feb-2046



Attention

If additional information is required, please contact your Cummins Warranty Operations Group Leader.



Description

This Safety Campaign is being issued to address an issue on certain ISX15 CM2250 SN and X15 CM2450 X124B/X134B units in which the flywheel may be susceptible to detaching from the crankshaft, possibly leading to loss of motive power, which may increase the risk of a crash. Additionally, driveline pieces may be ejected from the engine compartment, which may increase the risk of personal injury.

Cummins has reported this issue to the U.S. National Highway Traffic Safety Administration (NHTSA), which has assigned it Recall Number 21E-009.

This Safety Campaign authorizes certified repair locations to properly torque subject capscrews and inspect for possible damage and, if necessary, repair the damage on certain ISX15 CM2250 SN and X15 CM2450 X124B/X134B units.

Note : This field action provides for retroactive coverage of repairs completed by Cummins authorized repair locations prior to and in anticipation of the release date of this field action. All service providers attempting to file claims for retroactive repairs should reference Warranty Memo #1825 for instructions.

Note : This document does not authorize repairs for damage due to causes other than capscrews improperly torqued during the manufacturing process.



Action

In order to qualify for repair under this field action, an engine:

1. will be covered regardless of coverage status, and
2. must show as OPEN on QuickServe® Online for this field action.

Note : The ESN list is attached for reference.

After verifying that the engine meets the above requirements, perform the following actions:

1. Inspect the flywheel components for damage and reuse per procedure 016-005 (Flywheel) in the appropriate service manual.
2. Torque the flywheel capscrews per procedure 016-005 (Flywheel) in the appropriate service manual.

Note : Additional parts, such as o-rings, gaskets and fasteners, that are required to complete the repair, but not listed, may be claimed in Other Claimables. Please consolidate all consumables and claim them as one line item in Other Claimables titled CAMPAIGN SUPPLIES. Please include brief summaries on the details of items claimed.



Material Disposition

There are no materials involved in the field action.



Reimbursements

Parts

There are no parts covered in this field action.

Note : SRTs to gain access that are required to complete the repair, that are sufficiently explained in the claim narrative, may also be claimed on this action.

Note : All SRTs listed are OPTIONAL. Select ONLY the appropriate SRTs for the repair performed.

Labor Using Applicable Access Code and Time

SRT Code	Description	Time (hrs)
00-90X	Administrative time
16-05M	Flexplate or Flywheel – Remove and Install – X15 CM2450 X124B (OPTIONAL)
16-080	Flexplate or Flywheel – Remove and Install – X15 CM2450 X134B (OPTIONAL)
16-103	Flywheel or Flexplate – Remove and Install (OPTIONAL)
17-01J	Transmission, Manual – Remove and Install (CMI) (OPTIONAL)
17-151	TRANSMISSION, MANUAL – REMOVE AND INSTALL (OPTIONAL)



Travel

Travel is covered under this field action. Towing is covered under this field action.



Other Claimables

Consumables are covered under this field action.

Note : Additional parts, such as o-rings, gaskets and fasteners, that are required to complete the repair, but not listed, may be claimed in Other Claimables. Please consolidate all consumables and claim them as one line item in Other Claimables titled CAMPAIGN SUPPLIES or other appropriate selections. Please include brief summaries on the details of items claimed.



Claim Instructions

For Cummins Dealers, claims for this Field Campaign must be filed via RAPIDSERVE™ Web

(rsw.cummins.com). For information regarding RAPIDSERVE™ Web, please reference the “Warranty” tab in QuickServe® Online. If there are additional questions, please contact your local Cummins Distributor.

Claim Codes
Description	Code
Account Code:	65
Pay Code:	North America Distributor = X
Pay Code:	North America Dealer = D
Pay Code:	International Distributor = I
Pay Code:	International Dealer = R
Failure Code:	WSNCFB



Attachments

Click here to see c2402_esn-list.xlsx

(/service/english/attachments/c2402_esn-list.xlsx)

Engine Family	Fuel System
ISX, QSX15 ISX15
ISX, QSX15 ISX15
ISX, QSX15 ISX15
Design Application	Market Application
All	All
All	All
All	All



Document History

Date	Details
	Document Created; 25-Feb-2021



Last Modified: 25-Feb-2021



---

*** IMPORTANT SAFETY RECALL***
NHTSA Recall No. 21E009
Cummins Campaign #C2402



March 29, 2021



Dear Cummins Customer:

This notice is sent to you in accordance with the requirements of the National Traffic and Motor Vehicle Safety Act.

Cummins Inc. has decided that a defect which relates to motor vehicle safety exists in certain ISX Engines that were manufactured between October 27, 2020 and January 11, 2021.

This notice applies to your engine(s) listed in the table on the enclosed list.



WHY IS A RECALL BEING CONDUCTED?

The engine flywheel may be susceptible to detaching from the crankshaft, leading to loss of motive power, which may increase the risk of a crash.  Additionally, driveline pieces may be ejected from the engine compartment, which may increase the risk of personal injury.



WHAT ARE WE DOING ABOUT THE PROBLEM?

Cummins has released field Safety Campaign #C2402 “ISX15 CM2250 SN and X15 CM2450 X124B/X154B Flywheel Capscrew Retorque Safety Campaign” to correct this condition by properly torqueing the subject capscrews and inspecting for possible damage and, if necessary, repairing the damage.  This campaign is currently available at Cummins Distributors and authorized Warranty Dealers. The repair will be completed free of charge and most applications will require approximately nine hours to complete.



WHAT SHOULD YOU DO?

Contact the nearest Cummins Distributor or authorized Warranty Dealer to arrange to have this campaign performed on your engine.  The distributor or dealer will work with you to schedule the best date to complete this repair.



Federal law requires vehicle lessors receiving this recall notice to forward a copy of this notice to the lessee within ten (10) days.  Also, it is a violation of Federal law for a dealer to deliver a new vehicle or equipment covered by this recall notice under a sale or lease until the defect has been remedied.



WHO SHOULD YOU CONTACT IF YOU HAVE FURTHER QUESTIONS OR CONCERNS?

If you have questions or concerns about this recall, please contact your local Cummins Distributor or authorized warranty dealer.  You may also contact Cummins Care at 1-800CUMMINS (1-800-286-6467), or visit our website at care.cummins.com.



If you have a complaint relative to this recall, you may report it to the following:

Administrator
National Highway Traffic Safety Administration
1200 New Jersey Avenue, SE Washington, DC 20590



You may also call the toll-free Vehicle Safety Hotline at 1-888-327-4236 (TTY: 1-800-424-9153); or go to https://www.safercar.gov.



If you have not registered your Cummins product, please complete the enclosed registration card or register your product at https://prodreg.cummins.com/prodreg/#/webform/contactInfo.



If you are no longer the owner of the engine or vehicle listed in the table below, please forward this notice to the new owner or provide the new owner’s contact information to Cummins so that we can notify them of this recall.



Cummins is taking this action in the interest of safety and satisfaction with our products.  We apologize for any inconvenience and thank you for your attention to this matter.



Sincerely,



Campaign Administrator Cummins Inc.



---

1 Affected Product

Equipment

BRAND	PART NO.	PRODUCTION DATES
CUMMINS	X15



---
