NHTSA ID Number: 10194472
Manufacturer Communication Number: Bulletin 2019-5
Summary
Warranty Bulletin no 2019-5
Large Panoramic 7.8 ” Wide LCD Display- Software Update
Campaign no.: 2019–0008
February 12, 2019
No. 2019-5
Subject: Large Panoramic 7.8″ Wide LCD Display – Software Update
PROBLEM
A limited quantity of the MY19 vehicles were produced with a MY18 version of the multifunction gauge software.
SOLUTION
1. Connect the vehicle to the BRP diagnostic software (BUDS2) and update the multifunction gauge with the software update 20.80 or higher.
NOTE: A RED lightning will appear to indicate that an update is available.
The multifunction gauge software will evolve continually.
It is very important to check for latest updates at PDI and at every maintenance or repair.
CORRECTIVE ACTION
Required Tools
A personal computer (laptop or desktop)
MPI-2 INTERFACE CARD (P/N 529 036 018)
OR
MPI-3 INTERFACE CARD (P/N 529 036 353)
DIAGNOSTIC CABLE (P/N 710 000 851)
USB 2.0 or higher Cable (Type A Male to Type A Male) BRP (P/N 715900623) or equivalent available at electronic retail outlets. Do not exceed 2m (7 ft)
Update Procedure
Powering the Vehicle When Using BUDS2
NOTICE Make sure the unit’s battery is fully charged before undertaking this operation. Never use a battery charger to temporarily substitute the battery as it may cause the electronic modules to function erratically, or not at all. Continuous power to the computer is mandatory while performing this operation.
Spyder Service Flashing a Premium Multifunction Gauge 2018+ F3 and RT
Updating the Cluster
NOTE: Both diagnostic cable and USB cable are required to do the update.
1. MPI Diagnostic Cable
2. USB Cable
NOTICE Failure to follow these instructions thoroughly will prevent the re-flash.
Before undertaking the procedure ensure you are logged on the administrator account of the computer.
1. Access the vehicle USB connector.
2. Connect the USB cable between the computer and the vehicle.
3. Connect the vehicle to the BRP diagnostic software (BUDS2) using the MPI DIAGNOSTIC CABLE.
4. Logon as administrator by doing a right click on the BUDS2 icon and select the RUN AS ADMINISTRATOR option.
5. Ensure that your BRP diagnostic software (BUDS2) was updated to version 18.11.2 or higher and have EDB Dump Version 19.5.1 or higher. If not, update BUDS2 before continuing the update procedure.
NOTE: This new BUDS2 version includes the new software update 20.80.
6. In BUDS2, select:
– Flash page
– Cluster button
– Flash tab.
The first time an update is done with a computer, 2 dialog boxes will appear.
7. Click YES on the first one, and OK on the second.
8. Select and run the multifunction gauge software update file in the VALID FIRMWARE UPDATES window.
9. Follow instructions shown in the screen.
Once the software update is completed, a message box will confirm that the operation was successful.
If an error message occurs, click OK and repeat the procedure.
10. Start the radio and wait until the audio is functional in the speakers.
11. Turn the ignition key off and let the cluster gauge shut down.
SEOCONTENT-START
MODEL YEAR MODEL ADMISSIBLE UNITS
2019 F3 Series (T and Limited models)
RT Series
Go to BOSSWeb/Warranty/Campaign Monitoring
to know the quantity of units in your inventory
impacted by this campaign
IMPORTANT
– When a vehicle comes in for service, always type the VIN in Knowledge Center to
check for pending campaigns or alerts.
– When performing any work on a vehicle, it is good practice to connect it to BUDS2
to ensure that all needed updates are done.
CAUTION: All involved customers must be notified, all involved units must be corrected as per instruction herein.
On Line Assistance
For further assistance, visit the premium multifunction
gauge support site available on KNOWLEDGE
CENTER.
PremiumMultifunction Gauge – 134302
In the SPYDER TST DIRECTORY, find a new icon
for the premium multifunction gauge.
Click on this icon to be directed to the premium
multifunction gauge directory – 134302 which provides
4 main sections:
– Frequently asked questions
– “How to” videos
– Diagnostic
– Most recent software updates.
WARRANTY
Submit a warranty claim using the following information.
For claiming procedure, refer to the DEALER/DISTRIBUTOR
WARRANTY GUIDE.
Product Line Roadster
Unit Model Year 2019
Campaign/Bulletin/
Description
8 / 2019-5 / 7.8″ LCD
Display – Software
uUpdate
Total Labor time paid 0.2 hour
Expiration date April 30, 2022
SEOCONTENT-END
1 Affected Product
Vehicle
| MAKE | MODEL | YEAR |
| CAN-AM | SPYDER F3 | 2019 |
1 Associated Document
Manufacturer Communications
2019-5
February 12, 2019
MC-10194472-0001.pdf 749.748KB
