SRV-RCL-23-004 – Side Stand May Open Unexpectedly While Riding – 2018-2020 Ducati XDiavel S & XDiavel Standard Motorcycles

SEOCONTENT-START

OMB Control No.: 2127-0004 Part 573 Safety Recall Report 23V-620 The information contained in this report was submitted pursuant to 49 CFR §573 Manufacturer Name : Ducati North America Submission Date : SEP 06, 2023 NHTSA Recall No. : 23V-620 Manufacturer Recall No. : SRV-RCL-23-004 Manufacturer Information : Manufacturer Name : Ducati North America Address : 1292 Reamwood Avenue Sunnyvale CA 94089 Company phone : 650-933-9800 Population : Number of potentially involved : 842 Estimated percentage with defect : 2 % Vehicle Information : Vehicle 1 : 2018-2020 Ducati XDiavel S and standard Vehicle Type : MOTORCYCLES Body Style : OTHER Power Train : GAS Descriptive Information : On September 14, 2022, Ducati Motor Holding received the first report from the network about a motorcycle with the side stand springs retaining pin on the side stand bracket broken with consequential engine stalling. The case has been escalated to the Ducati Motor Holding’s pre-internal safety commission. Warranty and customer contact records were reviewed and analysed. Ducati Motor Holding become aware of a total of 18 reports about motorcycle with the side stand springs retaining pin on the side stand bracket broken. Dealers will install a new side stand bracket free of charge to the customer. The new side stand bracket has a springs retaining pin material is more robust. This impacts Model Year 2018-2020 and 842 units. Production Dates : JUN 08, 2017 – JUN 24, 2020 VIN Range 1 : Begin : ZDM13BKW3JB008130 End : ZDM13BKW9LB011620 ✔ Not sequential Description of Defect : Description of the Defect : The side stand springs retaining pin on the side stand bracket could wear out and in extreme cases could break, causing the side stand to open when it is in the raised position. FMVSS 1 : NR FMVSS 2 : NR Description of the Safety Risk : If the side stand open during the motorcycle riding, the side stand sensor will switch off the motorbike engine increasing the risk of crash and injury. Description of the Cause : NR Part 573 Safety Recall Report 23V-620 Page 2 The information contained in this report was submitted pursuant to 49 CFR §573 Identification of Any Warning that can Occur : If the side stand springs retaining pin on the side stand bracket break, the side stand would not remain in the raised position and remains in the open, so the rider may notice that the springs do not keep the side stand in the raised position or when the rider starts his motorbike, when he engages the gear, the side stand switch will switch off the engine. Involved Components : Component Name 1 : side stand bracket Component Description : side stand bracket Component Part Number : 556.2.105.2AA Supplier Identification : Component Manufacturer Name : NR Address : NR NR Country : NR Chronology : On September 14, 2022, Ducati Motor Holding received the first report from the network about a motorcycle with the side stand springs retaining pin on the side stand bracket broken with consequential engine stalling. On October 2022 the case has been escalated to the Ducati Motor Holding’s pre-internal safety commission. Warranty and customer contact records were reviewed and analyzed. On December 2022 the case has been escalated to the Ducati Motor Holding’s internal safety commission while the side stand bracket with the springs retaining pin broken was analyzed by the internal laboratory. On January 2023, has been started a constant and detailed monitoring of the field report. During the monitoring above, Ducati Motor Holding become aware of a total of 18 reports about motorcycle with the side stand springs retaining pin on the side stand bracket broken; none of these reports came from USA. Neither injuries, nor property damaged were reported in these cases. On September 05, 2023, Ducati Motor Holding’s internal safety commission decided to launch a recall Part 573 Safety Recall Report 23V-620 Page 3 The information contained in this report was submitted pursuant to 49 CFR §573 campaign to affected bike park. No injuries or property damaged have been reported. Description of Remedy : Description of Remedy Program : Ducati North America will notify dealers of this recall in accordance with the notification schedule. Dealers will install a new side stand bracket free of charge to the customer. A Ducati North America Recall Bulletin will be published to the Ducati Dealer Network using the established communication process. Requests for reimbursement for pre-notification repairs will be considered in accordance with Ducati’s general reimbursement plan on file with the agency. How Remedy Component Differs from Recalled Component : The new side stand bracket has a springs retaining pin material is more robust. Identify How/When Recall Condition was Corrected in Production : The same side stand bracket was introduced on DMH Ducati production line in October 2020. Recall Schedule : Description of Recall Schedule : Ducati North America Recall Bulletins will be published to the network of dealers through an established communication process. We estimate that we will initiate the Recall contact process for affected motorcycle owners during October 2023, but no later than 60 days from submission of this report. Planned Dealer Notification Date : SEP 12, 2023 – SEP 19, 2023 Planned Owner Notification Date : OCT 03, 2023 – OCT 10, 2023 * NR – Not Reported

**************************************************************************************************************

CR255 – Replacement of Side Stand Bracket and Spring Plate XDiavel Model Year 2018-2021 (all versions) Safety Recall Campaign SRV-RCL-23-004 1/14 Ducati North America www.ducati.com 1292 Reamwood Ave. Sunnyvale CA, 94089 Tel +1 650 933 9800 Date: September 12, 2023 To: Dealer Principal, General Manager, Service Manager, North American Dealer Network From: Richard Kenton, Technical Director Dan Schwartz, Service Area Manager Dear Dealers, As a result of the continuous quality checks on the product, we have decided to extend the fleet subject from the previous CR206 recall campaign, as we have found a potential concern with the Side Stand Mounting Bracket. In some rare cases the Spring Hooking Pin may break and cause the undesired extension of the Side Stand, even when riding. Unlike the previous CR206, this campaign does not require replacement of the side stand as it will need to be reused. The involved motorcycles will need to have the following parts replaced. • The Side Stand Mounting Bracket with a new version, Part no. 55621052AA which has been redesigned to avoid the above-described issue. • The Spring Hooking Plate with a new replacement, Part no. 82718981AA. Side Stand Bracket Part Number 55621052AA Spring Hooking Plate Part Number 82718981AA CR255 – Replacement of Side Stand Bracket and Spring Plate XDiavel Model Year 2018-2021 (all versions) Safety Recall Campaign SRV-RCL-23-004 2/14 Ducati North America www.ducati.com 1292 Reamwood Ave. Sunnyvale CA, 94089 Tel +1 650 933 9800 Table of Contents Page Introduction 1 Application 2 Client Impact 2 Parts Distribution 3 Warranty Reimbursement Rules 3 Spare Parts 3 Service Solution 4 Additional Requirements and Notes 11 Client Letter Example 12 Application You can find the precise list of VIN numbers involved in CR255 on the DCS, in sections: VIN HISTORY It is possible to search by individual frame number. CAMPAIGNS It is possible to search for all the frame numbers that you received from Ducati Motor Holding. Client Impact All motorcycles in your inventory (to be registered or already registered) and to be delivered to final Clients must be updated during pre-delivery operations and always before delivery to the final Clients. All motorcycles already delivered to final Clients must undergo this inspection as soon as they come to your workshop. All final Clients will be contacted concerning the service provided under this Safety Recall Campaign. CR255 – Replacement of Side Stand Bracket and Spring Plate XDiavel Model Year 2018-2021 (all versions) Safety Recall Campaign SRV-RCL-23-004 3/14 Ducati North America www.ducati.com 1292 Reamwood Ave. Sunnyvale CA, 94089 Tel +1 650 933 9800 Parts Distribution The component(s) required to carry out the upgrade under this Safety Recall Campaign must be ordered for each affected frame number. Warranty Reimbursement Rules Reimbursement for work associated with this Safety Recall Campaign will be made through the regular warranty claim procedure using the “Vehicle History” section of the DCS. The warranty claim is pre-filled and is identified as CR255. The Dealer shall be reimbursed for the parts listed for the operation; Side Stand Bracket (Part no. 55621052AA) and Spring Hooking Plate (Part no. 82718981AA), and labor for 30 minutes (5 labor units) that includes the time necessary for: • Vehicle reception and delivery • Side Stand Mounting Bracket replacement • Side Stand Spring Hooking Plate replacement • Compensation of consumables • The time for filling in the warranty claim • Soft cleaning of the vehicle Spare Parts The components to be used for this update are: PART NO. COMPONENT IMAGE QUANTITY 55621052AA Side Stand Bracket 1 82718981AA Spring Hooking Plate 1 CR255 – Replacement of Side Stand Bracket and Spring Plate XDiavel Model Year 2018-2021 (all versions) Safety Recall Campaign SRV-RCL-23-004 4/14 Ducati North America www.ducati.com 1292 Reamwood Ave. Sunnyvale CA, 94089 Tel +1 650 933 9800 Service Solution WARNING The procedure described in the document is not particularly difficult, however, for the operation to be completed successfully and to comply with the set time, it is necessary to thoroughly follow the sequence of the indicated operations. Therefore, we recommend taking your time to fully understand the procedure before attempting its implementation on the motorcycle (always print the document in color for a better understanding). 1. Position the motorcycle on a rear paddock stand. 2. Release side stand return internal spring (1) and external spring (2) from hook (3) and pin (4) groove. 3. Remove internal spring (1) and external spring (2) from plate (5). CR255 – Replacement of Side Stand Bracket and Spring Plate XDiavel Model Year 2018-2021 (all versions) Safety Recall Campaign SRV-RCL-23-004 5/14 Ducati North America www.ducati.com 1292 Reamwood Ave. Sunnyvale CA, 94089 Tel +1 650 933 9800 4. Remove special screw (6) securing side stand switch (7). 5. Remove nut M8x1.25 (8) and pin M8x1.25 (9) securing side stand to the relevant support bracket; then slide off the side stand. CR255 – Replacement of Side Stand Bracket and Spring Plate XDiavel Model Year 2018-2021 (all versions) Safety Recall Campaign SRV-RCL-23-004 6/14 Ducati North America www.ducati.com 1292 Reamwood Ave. Sunnyvale CA, 94089 Tel +1 650 933 9800 6. Remove screw M10x30 (10) and screw M10x50 (11) retaining the side stand bracket (12); then slide out bracket. 7. Take the new side stand bracket, Part no. 55621052AA. 8. Before installing the new side stand bracket Part no. 55621052AA, thoroughly clean the concerned area to remove any impurities. 9. Remove the Loctite present on screws M10x30 (10) and M10x50 (11). 10. Fit the new bracket (A) Part no. 55621052AA between crankcase and LH side bracket, as shown in the figure. CR255 – Replacement of Side Stand Bracket and Spring Plate XDiavel Model Year 2018-2021 (all versions) Safety Recall Campaign SRV-RCL-23-004 7/14 Ducati North America www.ducati.com 1292 Reamwood Ave. Sunnyvale CA, 94089 Tel +1 650 933 9800 11. Apply LOCTITE 648 along the threads of screw M10x30 (10). 12. Apply LOCTITE 648 along the threads of screw M10x50 (11). 13. Tighten the M10x30 screw (10) to a torque of 65 Nm and certify. 14. Tighten the M10x50 screw (11) to a torque of 42 Nm and certify. 15. Install the side stand on the mounting plate after applying Shell GADUS S2 V220AD2 grease (or equivalent) on the mating surfaces as shown in the figure. 16. Take pin M8x1.25 and apply Shell GADUS S2 V220AD2 grease (or equivalent) to the cylindrical part. Apply Loctite 243 to the threads, as shown in the figure. Loctite 648 Loctite 648 Loctite 243 Grease Shell GADUS S2 V220AD2 Grease Shell GADUS S2 V220AD2 Grease Shell GADUS S2 V220AD2 CR255 – Replacement of Side Stand Bracket and Spring Plate XDiavel Model Year 2018-2021 (all versions) Safety Recall Campaign SRV-RCL-23-004 8/14 Ducati North America www.ducati.com 1292 Reamwood Ave. Sunnyvale CA, 94089 Tel +1 650 933 9800 17. Insert pin M8x1.25 (9) and tighten to a torque of 24 Nm ± 10%. 18. Apply Loctite 243 on the threaded projection of pin M8x1.25 (8). 19. Start nut M8x1.25 (8) and tighten it to a torque of 18 Nm ± 10%. NOTE To tighten nut M8x1.25 (7), you must hold pin M8x1.25 (8) to lock out rotation. 20. Take the new plate. Loctite 243 New plate Part no. 82718981AA CR255 – Replacement of Side Stand Bracket and Spring Plate XDiavel Model Year 2018-2021 (all versions) Safety Recall Campaign SRV-RCL-23-004 9/14 Ducati North America www.ducati.com 1292 Reamwood Ave. Sunnyvale CA, 94089 Tel +1 650 933 9800 21. Insert internal spring (1) on external spring (2), aiming it as shown in the figure. 22. Hook spring ends to the new plate (B), aiming the parts as shown in the figure. 23. Fasten springs (1) and (2) to side stand hook (3) and insert the free hole of plate (B) inside the special groove on bracket pin (4), as shown in the figure. WARNING Plate (B) must be positioned as indicated by the red arrow. CR255 – Replacement of Side Stand Bracket and Spring Plate XDiavel Model Year 2018-2021 (all versions) Safety Recall Campaign SRV-RCL-23-004 10/14 Ducati North America www.ducati.com 1292 Reamwood Ave. Sunnyvale CA, 94089 Tel +1 650 933 9800 24. Install switch (7) on the side stand as shown in the figure. 25. Tighten special screw (6) to a torque of 5 Nm ± 10%. WARNING Insert the locating pin (12) of the switch in hole (13) of the stand. 26. Make sure that the side stand moves freely and check the correct operation of the safety switch: a. Perform a Key-ON, place the motorcycle on the side stand and check that the relevant warning light turns on. b. Retract the side stand and start the engine. c. Lower the side stand and engage first gear. The engine must switch off. 27. Remove the rear paddock stand. CR255 – Replacement of Side Stand Bracket and Spring Plate XDiavel Model Year 2018-2021 (all versions) Safety Recall Campaign SRV-RCL-23-004 11/14 Ducati North America www.ducati.com 1292 Reamwood Ave. Sunnyvale CA, 94089 Tel +1 650 933 9800 Campaign Authorization Ducati North America, Inc. will mail a notification letter to all known owners. If a client does not present this notification letter, it is important that you confirm the eligibility for recall status on the DCS before you commence work. Reimbursement requests for duplicate recall campaign repairs will not be accepted. Dealer Obligation This program is designed to complete the necessary repairs and to achieve owner satisfaction. Therefore, we ask that you take prompt and courteous action in accordance with these directives. Please provide a copy of this communication to every person in your dealership who has recall-related responsibilities. Please direct any questions or concerns to your Service Area Manager. Thank you for your cooperation. Service Department Ducati North America, Inc. For questions on this Workshop Campaign, please contact your Service Area Manager. CR255 – Replacement of Side Stand Bracket and Spring Plate XDiavel Model Year 2018-2021 (all versions) Safety Recall Campaign SRV-RCL-23-004 12/14 Ducati North America www.ducati.com 1292 Reamwood Ave. Sunnyvale CA, 94089 Tel +1 650 933 9800 This notice applies to your vehicle: VIN XXXXXXXXXXXXXXXXX NHTSA Recall No. 23V620 Date Client Name Client Address City, St, Zip Code Subject: Ducati Motorcycle: XDiavel Model Year 2018-2021 (all model and country versions) NHTSA Campaign I.D. Number: 23V620 Dealer Bulletin: SRV-RCL-23-004 Dear Ducati Owner, This notice is sent to you in accordance with the requirements of the U.S. National Traffic and Motor Vehicle Safety Act. Ducati Motor Holding S.P.A. has decided that a potential defect which relates to the side stand mounting bracket on XDiavel Model Year 2018-2023 (all model and country versions). Our records indicate that you are the owner of a Ducati motorcycle affected by this safety recall campaign. Please take the time to read this letter and help us take the appropriate steps to ensure that your vehicle is operating properly. It is necessary to replace the side stand bracket and spring hooking plate on your motorcycle. In some rare cases the spring hooking pin may break and cause the undesired extension of the side stand, even when riding which can result in a crash or injury. The involved motorcycles will need to have the Side Stand Mounting Bracket replaced with a new version along with the Spring Hooking Plate. The update can be easily completed by your Ducati Service Dealer. You are invited to contact your Ducati Service Dealer as soon as possible to make an appointment to carry out the update, which is completely free of charge. You can still continue to use your motorcycle to reach your Ducati Service Dealer, always check the side stand for correct operation before use. SAFETY RECALL CR255 – Replacement of Side Stand Bracket and Spring Plate XDiavel Model Year 2018-2021 (all versions) Safety Recall Campaign SRV-RCL-23-004 13/14 Ducati North America www.ducati.com 1292 Reamwood Ave. Sunnyvale CA, 94089 Tel +1 650 933 9800 During this recall, your Ducati Service Dealer shall also check whether it is necessary to make further interventions in order to keep your motorcycle updated, both at the mechanical and electronic level; in this case, it might be necessary for the workshop to keep your motorcycle for a longer period of time. To locate your nearest authorized Ducati dealer, please go to www.ducati.com, and select the “dealer locator” or you may call toll free from the U.S. 1-888-391-5446. Federal regulations require that any lessor receiving this recall notice must forward a copy of this notice to the lessee within ten days. Service Problem Help: If you believe that your dealer has failed or is unable to remedy the defect without charge, or within a reasonable period of time, please contact Ducati North America Client Care at 1 (888) 391-5446. If you still cannot obtain satisfaction, you may submit a written complaint to: For USA Clients: If you are still having difficulty getting your vehicle repaired in a reasonable time or without charge, you may write the Administrator, National Highway Traffic Safety Administration, 1200 New Jersey Ave. S.E., Washington, D.C. 20590 Or call the toll-free Vehicle Safety Hotline at 1-888-327-4236 (TTY 1- 800-424-9153), or go to www.nhtsa.gov. For Canadian Clients: Please contact Ducati client service at 1-888-391-5446 or for additional information about the recall you, can contact Transport Canada at 1-800-333-0510. TREAD ACT CLIENT REIMBURSEMENT PLAN If you have paid for the repair described in the attached letter, and you would like to be considered for reimbursement, please contact your authorized Ducati dealer. Expenses from repair facilities outside of the authorized Ducati dealer network will be considered; however, the procedure must meet Ducati North America’s standards. CR255 – Replacement of Side Stand Bracket and Spring Plate XDiavel Model Year 2018-2021 (all versions) Safety Recall Campaign SRV-RCL-23-004 14/14 Ducati North America www.ducati.com 1292 Reamwood Ave. Sunnyvale CA, 94089 Tel +1 650 933 9800 Your authorized Ducati retailer will request a copy of your owner notification letter, as well as, a copy of your previously paid invoice. They will inspect the vehicle, if still in your possession, prior to submitting a claim on your behalf to Ducati North America, Inc. for reimbursement. Only a repair involving this safety recall campaign is reimbursable. We recommend that your authorized Ducati dealer be your primary contact on this issue. We anticipate that your authorized Ducati dealer will be able to answer any questions that you may have regarding your qualifications for reimbursement of a previous repair; additionally, our Client Care Dept. may be contacted at 888-391-5446 for any special assistance required. What if you no longer own the vehicle? If you no longer own the vehicle, please e-mail your change of ownership information to Contact_Us@ducati.com or contact Ducati North America Client Care at 1 (888) 391-5446. We regret any inconvenience to you from this action; however, your safety and satisfaction are important to us. Sincerely, Richard Kenton Technical Director – Ducati North America

**************************************************************************************************************

**************************************************************************************************************

**************************************************************************************************************

**************************************************************************************************************

**************************************************************************************************************
