@[NOD
APR 1 3 2023
Compliance Dept
RV/CE PROCEDURE
23506
April, 2023
SUBJECT: SAFETY RECALL
Battery Box To Mounting Bracket Bolts on certain
2023 International® HV™ Series trucks built
04/29/2022 thru 06/30/2022 and 2023 and 2024
International® MV™ Series trucks built 02/24/2022
thru 01/04/2023 with feature code 08TTR, 0SVUL, or
0SVUX (Battery Box, steel, with plastic cover)
CUSTOMER LETTER
Print ready (PDF file) copy of the Customer Letter
DEFECT DESCRIPTION
The battery box to mounting bracket assembly bolts may not be present or
tightened to their specified assembly torque value, which can result in battery box
separation from the vehicle under certain rough road conditions. A battery box
that separates from a vehicle can increase the risk of a vehicle crash that may
result in property damage, personal injury, or death.
MODELS INVOLVED
This safety recall involves certain 2023 International® HV™ Series trucks built
04/29/2022 thru 06/30/2022 and 2023 and 2024 International® MV™ series trucks
built 02/24/2022 thru 01/04/2023 with feature code 08TTR, 08VUL, or 08VUX
(Battery Box, steel, with plastic cover).
ELIGIBILITY
This procedure applies ONLY to vehicles marked in the International® Service
Portal5M with Safety Recall 23506. Also complete any other open campaigns
listed on the Service Portal at this time.
VEHICLE RECALL 23506
© 2023 Navistar, Inc. All rights reserved. All marks are trademarks of their respective owners. 1
PARTS INFORMATION
NOTE: Less than 5% of the total population will require one or more
fasteners to be installed. Parts should be ordered using this percentage
for the vehicle that is being repaired.
Part Number Part Desc Quantit
3536430C1 As Needed
SERVICE PROCEDURE
WARNING! To prevent personal mJury and / or death, or damage to
property, park vehicle on hard flat surface, turn the engine off, set the
parking brake and install wheel chocks to prevent the vehicle from moving
in either direction.
WARNING! To prevent personal injury and/ or death, always wear safe eye
protection when performing vehicle maintenance.
WARNING! To prevent personal injury and I or death, or damage to
property, keep flames or sparks away from vehicle and do not smoke while
servicing the vehicle’s batteries. Batteries expel explosive gases.
1. Park vehicle on flat surface.
2. Shift transmission to Park or Neutral and set parking brake.
3. Turn vehicle ignition to Key OFF position.
4. Install wheel chocks.
NOTE: Battery box mounting brackets in Figure 1 illustrate the two
mounting bracket design types. Only one side of each battery box
assembly is shown in the images below because one is left frame mounted
and the other is right frame mounted.
VEHICLE RECALL 23506
Cl 2023 Navistar, Inc. All rights reserved. All marks are trademarks of their respective owners. 2
1 2 3
3 2 1
0000477455
Figure 1. Battery Box Inspection
1 . Battery box
2. Battery box mounting bracket
3. Battery box to battery box mounting bracket bolt (4)
5. Inspect both sides of battery box (Figure 1, Item 1) and identify battery box to
battery box mounting bracket bolt (Figure 1, Item 3).
a. If one or more bolts are missing, continue with Step 6.
b. If all four bolts are present, proceed to Step 7.
6. Install and hand tighten new bolts.
7. Using a torque wrench, tighten all 4 bolts to 158.5 lb-ft (215 N·m).
8. Remove wheel chocks.
END OF SERVICE PROCEDURE
VEHICLE RECALL 23506
@2023 Navistar, Inc. All rights reserved. All marks are trademarks of their respective owners. 3
LABOR INFORMATION
Operation Number Description Time
A40-23506-1 Torque All Four Bolts, Only 0.2 hrs
A40-23506-2
Install New Bolts If Necessary/ Torque All
0.4 hrs
Four Bolts
CAMPAIGN IDENTIFICATION LABEL
Each vehicle corrected in accordance with this
campaign must be marked with a CTS-1075
Campaign Identification Label.
Complete the label and attach on a clean surface next
to the vehicle identification number (VIN) plate.
ADMINISTRATIVE/ DEALER RESPONSIBILITIES
WARRANTY CLAIMS
COMPLETED
Service Location CGde’
Warranty claim expense is to be charged to Warranty. Claims are to be
submitted in the normal manner, making reference to Safety Recall 23506.
Section 7 of the Warranty Policy and Procedures Manual contains further
information related to the submission and processing of AFC / Recall claims.
As with all claim submissions, items acquired locally must be submitted in the
“Other Charges” tab. The cost of any bulk items (such as a bag of cable tie
straps, roll of wire, barrel of oil, or tube of silicone) should be prorated for the cost
of the individual pieces / amount used during each repair.
VEHICLE RECALL 23506
© 2023 Navistar, Inc. All rights reserved. All marks are trademarks of their respective owners. 4
GROUP – Enter n
NOUN – Leave b
umber
lank ~
+–
GROUP
I I I
–
C (CAUSE)- Enter either 1, 2, 3. (See below)
1. Inspected (No repair required).
2. Inspected and repaired.
3. Defective p art from parts stock. –
WARRANTY -CNa rranty Code) Enter 40. –
TYPE PART – En
PAD – Enter 1Xl
ter P for type part causing failure. –
UNITED STATES AND POSSESSIONS
NOUN C WARR. TP PAD
I I I
QICCI0,(1110
The National Traffic and Motor Vehicle Safety Act, as amended, provides that
each vehicle that is subject to a vehicle recall campaign must be adequately
repaired within a reasonable time after the owner has tendered it for repair. A
failure to adequately repair within 60 days after a tender of a vehicle is prima
facie evidence of failure to repair within a reasonable time. If the condition is not
adequately repaired within 60 days, the owner may be entitled to replacement
with an identical or reasonable equivalent vehicle at no charge, or to a refund of
the purchase price less a reasonable allowance for depreciation.
Dealers must correct all vehicles subject to this campaign at no charge to the
owner, regardless of mileage, age of vehicle, or ownership, from this time
forward.
Dealers should proceed immediately to make necessary correction to units in
inventory. All inventory vehicles subject to this recall campaign must be
corrected prior to sale, transfer or delivery. If vehicles have been sold or
transferred and you are in receipt of Customer Notification Letters and
Authorization for Recall Service cards for those vehicles, the transfer location or
customer must be notified immediately from your dealer location.
Dealers must make every effort to promptly schedule an appointment with each
owner to repair his or her vehicle as soon as possible. However, consistent with
the customer notification, dealers are expected to complete the repairs on the
mutually agreed upon service date.
Dealers involved in the recall process will be furnished a listing of owner names
and addresses to enable them to follow up with owners and have the vehicles
corrected. Use of this listing must be limited to this campaign because the list
may contain information obtained from state motor vehicle registration records,
and the use of such motor vehicle registration data for purposes other than this
campaign is a violation of law in several states.
VEHICLE RECALL 23506
© 2023 Navistar, Inc. All rights reserved. All marks are trademarks of their respective owners. 5
CANADA
Dealers must correct all vehicles subject to this campaign at no charge to the
owner, regardless of mileage, age of vehicle, or ownership, from this time
forward.
Dealers should proceed immediately to make necessary correction to units in
inventory. All inventory vehicles subject to this recall campaign must be
corrected prior to sale, transfer or delivery. If vehicles have been sold or
transferred and you are in receipt of Customer Notification Letters and
Authorization for Recall Service cards for those vehicles, the transfer location or
customer must be notified immediately from your dealer location.
Dealers must make every effort to promptly schedule an appointment with each
owner to repair his or her vehicle as soon as possible. However, consistent with
the customer notification, dealers are expected to complete the repairs on the
mutually agreed upon service date.
Dealers involved in the recall process will be furnished a listing of owner names
and addresses to enable them to follow up with owners and have the vehicles
corrected. Use of this listing must be limited to this campaign because the list
may contain information obtained from state motor vehicle registration records,
and the use of such motor vehicle registration data for purposes other than this
campaign is a violation of law in several states.
EXPORT
Export Distributors should proceed immediately to make necessary correction to
units in inventory. All inventory vehicles subject to this recall campaign must be
corrected prior to sale, transfer or delivery. If vehicles have been sold or
transferred and you are in receipt of Customer Notification Letters and
Authorization for Recall Service cards for those vehicles, the transfer location or
customer must be notified immediately from your distributor location.
Export Distributors are to submit warranty claims in the usual manner making
reference to this recall number.
Export Distributors are expected to provide full cooperation and follow-up with
respect to this important subject matter. If you have any questions or need
further assistance, please contact the Regional Service Manager at your regional
office.
NAVISTAR, INC.
VEHICLE RECALL 23506
© 2023 Navlstar, Inc. All rights reserved. All marks are trademarks of their respective owners. 6

**************************************************************************************************************

Navistar, Inc.
2701 Navistar Drive
Lisle, IL 60532 USA
navistar.com
IMPORTANT SAFETY RECALL 23506
NHTSA RECALL NO. 23V-154
This notice applies to your vehicle identified on the
enclosed card.
Dear INTERNATIONAL® Customer,
This notice is sent to you in accordance with the
requirements of the National Traffic and Motor Vehicle
Safety Act.
Navistar has decided that a defect which relates to motor
vehicle safety exists in certain 2023 HV® series trucks built
04/29/2022 thru 06/30/2022 and 2023 and 2024 MV®
series trucks built 02/24/2022 thru 01/04/2023 with feature
code 08TTR, 08VUL, or 08VUX (Battery Box, steel, with
plastic cover) manufactured at the San Antonio facility.
REASON FOR THIS RECALL
The battery box to mounting bracket assembly bolts may
not be present or tightened to their specified assembly
torque value which can result in battery box separation
from the vehicle under certain rough road conditions.
RISK TO MOTOR VEHICLE SAFETY
A battery box that separates from a vehicle can increase
the risk of a vehicle crash that may result in property
damage, personal injury, or death.
DEFECT REMEDY
The repair will involve installing all missing battery box to
battery box mounting bracket bolts and tightening all four
bolts to their specified torque value. Authorized repair
locations have parts and instructions to repair your vehicle.
The repair will be performed free of charge and take
approximately 45 minutes to complete.
ACTIONS YOU SHOULD TAKE
If you own this vehicle, please schedule an appointment
with any Authorized repair center to have your vehicle
repaired. You can find your nearest dealer by using the
dealer locator at
https://www.intemationaltrucks.com/dealer-locator or by
calling 1-800-448-7825 or find the nearest Love’s center at
https://www.loves.com .
UYXJ~□ [bl:§[ID
APR 2 8 2023
By: .l;.<;.:(!.’_~~_.l.f.~ ..c…£…
A NAVISTAR COMPANY
APRIL 2023
*Love’s and Speedco locations in Texas cannot perfonn
warranty services.
If you have already paid for repairs prior to this notice
that corrected the defect, you may be eligible for
reimbursement of certain repair expenses if they occurred
03/08/2022 thru 05/08/2023. Present your original repair
paperwork and proof of payment to any
INTERNATIONAL• dealer and your eligibility will be
reviewed. You may also submit a claim using the enclosed
Request for Reimbursement card.
If you are the lessor of this vehicle, please forward a
copy of this notice to the lessee within ten days to comply
with federal regulations.
If you do not own this vehicle, please fill out and return
mail the enclosed card so that you will not be contacted
again about this recall.
IF YOU NEED FURTHER ASSISTANCE
If you believe that Navistar has failed to remedy the defect
without charge or within a reasonable time, please follow
the procedure described in the Owner Assistance Guide
section in your Owner’s Manual or call toll free 1-800-448-
7825.
You may also submit a· complaint to the Administrator,
National Highway Traffic Safety Administration, 1200 New
Jersey Ave, SE, Washington, DC 20590; or call the toll
free Vehicle Safety Hotline at 1-888-327-4236 (TTY: 1-800-
424-9153); or go to http://www.safercar.gov.
Navistar requests your prompt attention and patience
regarding the correction of this defect and apologizes for
any inconvenience this may cause you.
Navistar, Inc.

**************************************************************************************************************

OMB Control No.: 2127-0004
Part 573 Safety Recall Report 23V-154
The information contained in this report was submitted pursuant to 49 CFR §573
Manufacturer Name : Submission Date :
Navistar, Inc. MAR 08, 2023 NHTSA Recall No. : 23V-154 Manufacturer Recall No. : 23506 Manufacturer Information :
Manufacturer Name : Navistar, Inc.
Address : 2701 Navistar Drive
Lisle IL 60532 Company phone : 331-332-1590
Population :
Number of potentially involved : 791 Estimated percentage with defect : 5 %
Vehicle Information : Vehicle 1 : 2023-2023 International HV
Vehicle Type : BUSES, MEDIUM & HEAVY VEHICLES Body Style : OTHER Power Train : DIESEL
Descriptive Information : • The suspect population is identified by models equipped with feature code 08TTR, 08VUL, or 08VUX (Battery Box, steel, with plastic cover).
• The inclusive dates of manufacture were determined by when the San Antonio manufacturing plant began production of the HV® and MV® series trucks through the date the issue was contained in production.
• The vehicles in the suspect population were assembled at the San Antonio assembly plant and all other similar vehicles not in the suspect population were assembled at Navistar’s other manufacturing plants.
There are 5 HV series trucks in the suspect population.
Production Dates : APR 29, 2022 – JUN 30, 2022
VIN Range 1 : Begin : NR End : NR ntial Part 573 Safety Recall Report 23V-154 Page 2 Vehicle 2 : 2023-2024 International MV
Vehicle Type : BUSES, MEDIUM & HEAVY VEHICLES Body Style : OTHER Power Train : DIESEL
Descriptive Information : • The suspect population is identified by models equipped with feature code 08TTR, 08VUL, or 08VUX (Battery Box, steel, with plastic cover).
• The inclusive dates of manufacture were determined by when the San Antonio manufacturing plant began production of the HV® and MV® series trucks through the date the issue was contained in production.
• The vehicles in the suspect population were assembled at the San Antonio assembly plant and all other similar vehicles not in the suspect population were assembled at Navistar’s other manufacturing plants.
There are 786 MV series trucks in the suspect population.
Production Dates : FEB 24, 2022 – JAN 04, 2023
VIN Range 1 : Begin : NR End : NR Not sequential Description of Defect :
Description of the Defect : The battery box to mounting bracket assembly bolts may not be present or tightened to their specified assembly torque value which can result in battery box separation from the vehicle under certain rough road conditions.
FMVSS 1 : NR FMVSS 2 : NR
Description of the Safety Risk : A battery box that separates from a vehicle can increase the risk of a vehicle crash resulting in property damage, personal injury, or death.
Description of the Cause : The cause of the defect is still under investigation. Identification of Any Warning
that can Occur : None Involved Components : Component Name 1 : Bolt
Component Description : BOLT HEX FLG HD M16-2 X 30 Component Part Number : 3536430C1 Supplier Identification : The information contained in this report was submitted pursuant to 49 CFR §573 Part 573 Safety Recall Report 23V-154 Page 3 Component Manufacturer
Name : NR Address : NR
NR
Country : NR Chronology :
• 01/05/2023 – Navistar manufacturing initiates ship hold at the San Antonio manufacturing plant when a battery box fell off its mounting brackets to a vehicle while the vehicle was decked onto another vehicle for transport and communicates the issue to Compliance.
• 01/10/2023 – Navistar Manufacturing and Compliance meet to review the issue.
• 01/11/2023 through 01/17/2023 – Navistar investigates and determines the potentially affected battery box styles.
• 01/17/2023 through 02/27/2023 – Navistar inspects and repairs the quarantined vehicles at the manufacturing plant.
• 02/14/2023 and 02/15/2023 Navistar meets with their truck transport company for additional information related to the fallen battery box that occurred on 01/05/2023.
• 02/14/2023 through 02/22/2023 – Navistar Engineering performs battery box mounting tests and concludes all four fasteners between the battery box and battery box mounting bracket and/or the bolts tightened to their specified torque value, are required to meet the design life.
• 02/28/2023 – Navistar determines the suspect vehicle population.
• 03/02/2023 – Navistar declares a Safety Recall. Description of Remedy :
Description of Remedy Program : • The remedy will involve replacing all missing battery box to
battery box mounting bracket bolts and tightening all four bolts to their specified torque value.
• Navistar’s plan for reimbursement of pre-notification remedies, on file with NHTSA and dated 05/06/2022, applies and reimbursement instructions will be included in the customer notification. How Remedy Component Differs from Recalled Component : Identify How/When Recall Condition was Corrected in Production : The remedy assembly involves replacing any missing bolts and tightening the four bolts to their specified torque value and the recalled assembly did not validate this process.
01/05/2023 – Navistar revises work instructions to include witness marks to each bolt that has attained correct assembly torque specification and a second witness mark at quality inspection. Recall Schedule : The information contained in this report was submitted pursuant to 49 CFR §573 Part 573 Safety Recall Report 23V-154
Page 4
The information contained in this report was submitted pursuant to 49 CFR §573
Description of Recall Schedule : It is estimated that the Customer and Dealer notification letters will be
mailed by 05/05/2023.
Planned Dealer Notification Date : MAY 05, 2023 – MAY 05, 2023
Planned Owner Notification Date : MAY 05, 2023 – MAY 05, 2023
* NR – Not Reported

SEOCONTENT-END
